Поз.
Артикул
Описание
18
BRAKE PEDAL
23
PAD , 016,017,018 UP TO IDENT NO. 739255 EXCEPT FOR 500001-599999 UP TO IDENT NO. 4 667210,FROM IDENT NO.SEE SA 25011
29
BRACKET BRAKE PEDAL THRU CAB FLOOR, 032,033,040,041,132,133,140,141 FROM ENGINE 031700 040,041,140 UP TO CHASSIS 085315 344.141 LESS SUPERCHARGING SYSTEM UP TO CHASSIS 031699 ON LK 1113 WITH CAB 814 FROM CHASSIS 12326709
34
GUIDE BRAKE PEDAL THRU CAB FLOOR, USED WITH HYDRAULIC BRAKE,UP TO CHASSIS 589554
39
SHIM BRACKET TO CAB FLOOR
45
SCREW CABLE TO ALTERNATOR
50
NUT PUMP TO BRACKET
61
NUT , Replaced By: N304032008006
66
LEVER (REVERSING LEVER)
72
BALL PIVOT INTERMEDIATE LEVER
78
YOKE OPERATING ROD
83
PIN YOKE TO LEVER
89
SPRING WASHER PLATE TO PLATE AND TO LEVER
94
WASHER TRAILER PLUG SOCKET TO BRACKET
100
COTTER PIN LEVER TO ROD, Replaced By: N000094002060
105
FITTED WASHER LEVER TO BRACKET
110
LOCK RING SHOCK ABSORBER TO BRACKET,1D 006005
116
SPRING , 309.300-326 UNTIL PRODUCTION STOP 309.370-391 UP TO CHASSIS 014221,309.400-426 UP TO CHASSIS 095115,310.300-326,400-426 UP TO CHASSIS 019232 FROM CHASSIS SEE STANDARDVERSION
121
NUT REVERSING LEVER AND DOUBLE LEVER
126
SCREW SHIFT LEVER TO TRANSMISSION
131
BRACKET MASTER CYLINDER
136
BUSHING
142
LOCK WASHER EXTENSIBLE BRAKE VALVE TO CAB
147
SCREW CLAMP TO BRACKET
152
ROD OPERATING ROD
163
BALL SOCKET AT CONTROL LEVER
168
NUT
173
SECURING CLIP. CIRCLIP ACCELERATOR CONTROL
178
LEVER EXHAUST BRAKE INTERMEDIATE LEVER
184
LEVERII
194
BALL PIVOT ACCELERATOR PEDAL,4 859026
199
SPRING WASHER
205
NUT
210
FITTED WASHER LEVER TO BRACKET
216
LOCK RING SHOCK ABSORBER TO BRACKET,1D 006005
221
BRACKET LEVER II
227
BUSHING
232
LOCK WASHER EXTENSIBLE BRAKE VALVE TO CAB
237
SCREW CLAMP TO BRACKET
247
ROD FROM INTERMEDIATE LEVER TO THROTTLE VALVE
253
BALL SOCKET AT CONTROL LEVER
258
NUT
263
SECURING CLIP. CIRCLIP ACCELERATOR CONTROL
999
SHIM , Replaced By: A3454347087
999
SHIM BRAKE PEDAL THRU CAB FLOOR, 032,033,040,041,132,133,140,141 FROM ENGINE 031700 040,041,140 UP TO CHASSIS 085315 344.141 LESS SUPERCHARGING SYSTEM UP TO CHASSIS 031699 ON LK 1113 WITH CAB 814 FROM CHASSIS 12326709
999
ROD FROM INTERMEDIATE LEVER TO INTERMEDIATE SHAFT LEVER
999
ROD , Replaced By: A3084307092
999
RODTO 308 430 70 92
999
STOP , NOT USED
