Поз.
Артикул
Описание
6
SWITCH P.T.O. TELL-TALE LAMP
13
FITTING EXHAUST BRAKE SWITCH TO SIGNAL PRESSURE CONNECTION AT TRANSMISSION
20
UNION NUT
27
SEAL CONE
27
GLAND , Replaced By: A0019901667
34
FITTING , Replaced By: A0009907171
41
DRIVE FLANGE P.T.O.
41
DRIVE FLANGE PROPELLER SHAFT TO TRANSMISSION
41
DRIVE FLANGE PROPELLER SHAFT TO TRANSMISSION
62
SCREW INTERMEDIATE FLANGE TO COUPLING FLANGE
69
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
76
NUT FROM PROPELLER SHAFT TO FRONT AXLE
78
FLANGE P.T.O.
78
FLANGE P.T.O.
78
FLANGE P.T.O.
78
FLANGE (OUTPUT FLANGE)
80
NUT OUTPUT FLANGE
80
NUT OUTPUT FLANGE
83
LEVER SHIFTING LEVER
83
LEVER GEARSHIFT,TRANSMISSION
83
LEVER SHIFTING LEVER
83
LEVER SHIFTING LEVER
90
OIL FILLER PIPE ALLISON AUTOMATIC TRANSMISSION
90
OIL FILLER PIPE ALLISON AUTOMATIC TRANSMISSION
90
OIL FILLER PIPE ALLISON AUTOMATIC TRANSMISSION
90
OIL FILLER PIPE ALLISON AUTOMATIC TRANSMISSION
90
OIL FILLER PIPE ALLISON AUTOMATIC TRANSMISSION
97
OIL DIPSTICK ALLISON AUTOMATIC TRANSMISSION
97
OIL DIPSTICK ALLISON AUTOMATIC TRANSMISSION
97
OIL DIPSTICK ALLISON AUTOMATIC TRANSMISSION
97
OIL DIPSTICK ALLISON AUTOMATIC TRANSMISSION
97
OIL DIPSTICK ALLISON AUTOMATIC TRANSMISSION
100
PIPE SOCKET OIL FILLER NECK
104
BRACKET OIL LINE TO FRAME
104
BRACKET OIL FILLER NECK
104
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
104
BRACKET OIL FILLER NECK
110
BRACKET OIL FILLER NECK
122
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
128
SCREW BRACKET TO TRANSMISSION, TO BE ADAPTED DURING ASSEMBLY
134
SCREW BRACKET TO TRANSMISSION
140
CLAMP FEED LINE TO THERMOSTAT
140
CLAMP COOLING WATER LINE TO FIRE WALL
146
SPACER RING INTERMEDIATE RING TO TIMING CASE
152
FOLLOWER CONVERTER
158
DISC INTERMEDIATE FLANGE
164
SCREW , Replaced By: N910105012003
164
HEXAGON HEAD BOLT. SCREWM 12X1,5X20 MM - TO A 202 490 08 41
170
SCREW DRIVEN DISC TO CONVERTER
176
SCREW EXHAUST PIPE TO BRACKET
176
SCREW BRACKET TO SIDE MEMBER
176
HEXAGON HEAD BOLT BRACKET TO BRACKET
176
SCREW , Replaced By: N304017010002
182
SCREW BEARING BRACKET TO STEERING COLUMN BRACKET
188
WASHER RADIATOR TO RUBBER MOUNTING
194
SPRING WASHER STEERING COLUMN BRACKET TO CAB
200
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
999
MAGNETTO 000 270 29 89
999
VALVE , Replaced By: A0022601757
999
VALVE REPAIR KIT TO 000 270 29 89
999
FITTING TEST PLUG CONNECTION
999
STOP WIRE CABLE,REAR
999
NUT , Replaced By: A1170700041
999
PIN APPARATUS PLATE
999
SCREW CLAMP MOUNTING M 6X16
999
SCREW , Replaced By: N000000001146
999
NUT SPRING-LOADED PUSH ROD
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
