Поз.
Артикул
Описание
30
BRAKE ANCHOR FRONT AXLE,LEFT
30
BRAKE ANCHOR FRONT AXLE,RIGHT
30
BEARING BRACKET , Replaced By: A6584210406
30
BEARING BRACKET , Replaced By: A6584210506
34
BUSHING OUTSIDE
35
BUSHING INSIDE
36
SEAL RING OUTSIDE BEARING BRACKET
36
SEAL RING INSIDE BEARING BRACKET
36
SEAL RING INSIDE BEARING BRACKET
36
SEAL RING INSIDE BEARING BRACKET
36
SEAL RING , Replaced By: A0129974147
36
SEAL RING OUTSIDE BEARING BRACKET
36
SEAL RING OUTSIDE BEARING BRACKET
38
GREASE NIPPLE INTERMEDIATE LEVER
38
GREASE NIPPLE
42
SCREW BEARING BRACKET TO BRAKE ANCHOR
44
NUT , Replaced By: A0009905750
44
NUT BEARING BRACKET TO BRAKE ANCHOR
48
SPACER WASHER ADJUSTER TO BRAKE CAMSHAFT
50
BRAKE CAMSHAFT WITH LUBRICATING BORE,LEFT
50
BRAKE CAMSHAFT , Replaced By: A6234210536
50
BRAKE CAMSHAFT , Replaced By: A6234210636
50
BRAKE CAMSHAFT WITH LUBRICATING BORE,RIGHT
53
ADJUSTER AUTOMATIC,RIGHT
53
ADJUSTER AUTOMATIC,LEFT
65
SPACER WASHER ADJUSTER,AS REQUIRED 0.50 MM
65
SPACER WASHER ADJUSTER,AS REQUIRED 1.50 MM
65
SPACER WASHER ADJUSTER,AS REQUIRED 2.50 MM
65
SPACER WASHER ADJUSTER,AS REQUIRED 2.00 MM
67
STOP WASHER SLACK ADJUSTER TO BRAKE SHAFT
69
PIN ADJUSTER STOP
79
SPACER WASHER ADJUSTER
81
LOCK RING ADJUSTER TO BRAKE CAMSHAFT
83
WHEEL BRAKE CYLINDER (TRISTOP CYLINDER),LEFT WABCO, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
83
WHEEL BRAKE CYLINDER (TRISTOP CYLINDER),RIGHT WABCO, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
85
DIAPHRAGMTO 008 420 23 18,WABCO
89
CUP , Replaced By: A0004213886
89
CUPTO 007 420 68 18,WABCO
93
FITTINGWABCO
103
REPAIR KIT (DIAPHRAGM CYLINDER),FRONT AXLE TO WABCO
109
NUT COMBINATION CYLINDER TO BEARING BRACKET, Replaced By: N910113016002
111
PIN COMBINATION CYLINDER TO SLACK ADJUSTER
113
WASHER , Replaced By: N000433015005
115
COTTER PIN STRAP TO SUPPORT
148
BRAKE DRUM
