Поз.
Артикул
Описание
10
TRUNK LID
10
TRUNK LID
20
HINGE LEVER RIGHT
20
HINGE LEVER LEFT
30
INTERMEDIATE LAYER PARTS KIT
50
SCREW INTAKE SHELL TO BRACKET,A 213305
60
SCREW HINGE LEVER TO MOUNTING
70
NUT BRACKET TO BATTERY IMPLEMENT CARRIER M8
80
RETAINER WEDGE TRUNK LID, RIGHT
80
STOP HINGE LEVER BEARING
90
NUT , Replaced By: N913023006001
100
EXTENSION SPRING
110
INSULATION TENSION SPRING
150
TRIM PANEL TRUNK LID , 9F08QFT204A0106 SINGLE TONE BLACK
150
TRIM PANEL TRUNK LID , 9F08QFT204A0106 SINGLE TONE BLACK
190
PLUG-IN MOUNTING LEFT PANELLING TO BODY, F 50004620100331
200
SEALING FRAME
220
HANDLE
230
BODY-BOUND NUT CONTROL UNIT FIXTURE
240
FILLISTER HD SCREW MOUNTING, SPOILER AND STOP LAMP
250
PLUG-IN MOUNTING LEFT PANELLING TO BODY, F 50004620100331
260
INTERIOR LAMP IN REAR-END DOOR
270
LAMP HOLDER INTERIOR LAMP 12V-5W, J 42086420061222
280
BULBTO A 6955407048/7148,3825400311/0411
290
STOP BUFFER BOTTOM
300
DUCT REAR LID HINGE,RIGHT
300
DUCT REAR LID HINGE,LEFT
310
PLUG-IN MOUNTING LEFT PANELLING TO BODY, F 50004620100331
330
SWITCH LUGGAGE COMPARTMENT INTERIOR CONTROL, A 23717420010831 F 16659520010831
350
RETAINER WEDGE TOP
360
STOP PLUG BATTERY CASE 6.5 MM
360
PLUG
370
GUIDE SIGN TO CABLE DUCT
900
PLUG HOUSING BUS NODE ROOF 6-PIN MQS,N70/3
912
PIN BUSHING HOUSING. PLUG CONNECTOR FOR POTENTIAL DISTRIBUTOR (CAN),COCKPIT
