Поз.
Артикул
Описание
10
TS BRAKE BOOSTER PARTS KIT
10
BRAKE BOOSTER ASSEMBLY PARTS KIT
10
TS BRAKE BOOSTER PARTS KIT
10
BRAKE BOOSTER ASSEMBLY PARTS KIT, F 01529620070531
20
SEALING PLUGS VACUUM LINE AT BRAKE BOOSTER
30
GASKET BRAKE BOOSTER TO BEARING BRACKET
40
NUT BRACKET TO BATTERY IMPLEMENT CARRIER M8
50
PIN BRAKE UNIT TO PEDAL ASSEMBLY
70
PRESSURE SENSOR VACUUM SENSOR IN BRAKE UNIT
100
BRAKE MASTER CYLINDER PARTS KIT
100
MASTER BRAKE CYLINDER PARTS KIT
100
BRAKE MASTER CYLINDER PARTS KIT, Replaced By: A2044300501
110
STOP PLUG EXPANSION RESERVOIR TO MASTER CYLINDER
120
SEAL RING
130
NUT BRACKET TO BATTERY IMPLEMENT CARRIER M8
150
DASHPOT
150
DASHPOT
160
COVER
170
STRAINER
180
BOLT EXPANSION RESERVOIR TO MASTER CYLINDER
200
LINE BRAKE BOOSTER TO PARTITION POINT
200
VACUUM LINE BRAKE BOOSTER TO VACUUM PUMP OR TO INTAKE MANIFOLD, A 20131207 G 20131130
200
VACUUM LINE BRAKE BOOSTER TO VACUUM PUMP OR TO INTAKE MANIFOLD, G 20131130
210
VACUUM LINE SEPARATION POINT TO VACUUM PUMP OR TOTHE INTAKE MANIFOLD
300
FEED-THROUGH GROMMET LOWER PART
310
FEED-THROUGH GROMMETOBERTEIL, A 58879420110630 L 05094120110630 V 00365520110630 F 73545920110707 L 15437920111012
902
CLUTCH BRAKE ASSIST SYSTEM CONNECTION 3-PIN SLK2.8,A7/7
