Поз.
Артикул
Описание
338
CONSOLE CAB MOUNTING,FRONT
339
BOW CAB MOUNTING,FRONT
340
STRUT BUMPER,RIGHT
340
STRUT BUMPER,LEFT
341
SCREW , Replaced By: N308676014012
341
SCREW APPARATUS SUPPORT TO FRAME
341
SCREW , Replaced By: A9429901304
341
SCREW SUPPORT TO SIDE MEMBER M 14X45
342
NUT , Replaced By: N910113014000
342
NUT STEERING SUPPORT TO FRAME
343
SCREWM 16X18X26X48
344
WASHER SHOCK ABSORBER TO UPPER BEARING BRACKET
345
NUT , Replaced By: N910113016001
345
NUT CONSOLE TO SUPPORT
347
BRACKET RIGHT BUFFER
347
BRACKET LEFT BUFFER
349
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
350
WASHER SPARE WHEEL CARRIER
352
NUT BRACKET TO SIDE MEMBER
352
NUT , Replaced By: N910113014001
353
MOUNTING (RUBBER BUFFER)
354
SCREW , Replaced By: N304017008034
354
SCREW BRACKET TO CROSS CONNECTION STRUT
355
WASHER , Replaced By: N009021008213
355
WASHER BRACKET TO LEFT SIDE MEMBER
356
NUT , Replaced By: N913004008001
356
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
356
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
357
MOUNTING CAB SUSPENSION,FRONT LEFT
357
MOUNTING CAB SUSPENSION,FRONT RIGHT
358
SPRING CAB SUSPENSION,FRONT
359
BUSHING SPRING
360
GREASE NIPPLE FOR SPRING
364
LEVER (TILTING LEVER),CAB
368
BUSHING TILTING LEVER
368
BUSHING TILTING LEVER
372
BUFFER TILTING LEVER
376
BUSHING ON TOGGLE LEVER,FOR HYDRAULIC CYLINDER
380
HEADLESS SETSCREW FOR SPRING
388
MOUNTING CAB TILTING LEVER
392
SCREW , Replaced By: N308676012012
392
SCREW END PIECE TO EXHAUST PIPE M 10X25
392
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
396
LOCK WASHER FITTING TO BRACKET
396
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
400
SHOCK ABSORBER (VIBRATION ABSORBER),CAB REAR SUSPENSION
400
SHOCK ABSORBER (VIBRATION ABSORBER),CAB REAR SUSPENSION
404
RUBBER MOUNTING
408
BUSHING
412
WASHER , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A6203170176
412
WASHER VIBRATION ABSORBER TO BEARING AND TO CAB
416
WASHER , Replaced By: N000125013008
416
WASHER
420
NUT SUPPORT TO SIDE MEMBER
428
WASHER STABILIZER TO BEARING
432
STABILIZER CAB SUSPENSION,FRONT, USED WITH MERCEDES-BENZ MEDIUM-LENGTH/LONG/LARGE-CAPACITY CABS
432
STABILIZER , Replaced By: A6558900004
436
JOINT BEARING , Replaced By: A0019814631
436
JOINT BEARING
440
GREASE NIPPLE FOR SPRING
444
SCREW PLUG STABILIZER
452
MOUNTING ,5 178428, Replaced By: A6218900403, +001A6203100177
452
MOUNTING SPRING AND STABILIZER,RIGHT
452
MOUNTING ,5 178428, Replaced By: A6218900503, +001A6203100177
452
MOUNTING SPRING AND STABILIZER,LEFT
460
PIN
464
SCREW BRACKET TO CROSS CONNECTION STRUT
464
SCREW , Replaced By: N304017008034
468
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
468
NUT , Replaced By: N913004008001
468
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
472
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
472
SCREW MOUNTING TO CAB
480
WASHER SPARE WHEEL CARRIER
484
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
486
SCREW STABILIZER TO BEARING
488
NUT , Replaced By: N910113014001
488
NUT BRACKET TO SIDE MEMBER
492
CONSOLE CAB SUSPENSION,FRONT LEFT
492
CONSOLE CAB SUSPENSION,FRONT RIGHT
496
SCREW , Replaced By: N308676012015
496
SCREW LEFT AND RIGHT CONSOLES TO CAB
500
SCREW LEFT AND RIGHT CONSOLES TO CAB M 12X30
504
LOCK WASHER FITTING TO BRACKET
508
WASHER LEFT AND RIGHT CONSOLES TO CAB
512
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
512
SCREW , Replaced By: N308676014020
516
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
520
SHIM MOUNTING TO CONSOLE
524
HEXAGON HEAD BOLT. SCREW ENGINE MOUNTING TO SUPPORT,ON CLUTCH END M 14X30
524
SCREW , Replaced By: N308765014008
524
SCREW , Replaced By: N308676014003
524
SCREW MOUNTING TO SIDE MEMBER M 14X85
524
HEXAGON HEAD BOLT. SCREW SUPPORT TO SIDE MEMBER M 14X100
536
WASHER SPARE WHEEL CARRIER
540
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
544
NUT , Replaced By: N910113014000
544
NUT STEERING SUPPORT TO FRAME
548
BUFFER (HOLLOW RUBBER SPRING),CAB
552
FLANGE HOLLOW RUBBER SPRING
556
BUSHING HOLLOW RUBBER SPRING
560
SCREW BRACKET TO SIDE MEMBER
560
SCREW , Replaced By: N304017010002
566
WASHER HOLLOW RUBBER SPRING TO CAB,5 956657
566
WASHER , Replaced By: A4432610076
999
LOCK PULL TO FASTENER
999
LOCK , Replaced By: N912002008003
999
SCREW MOUNTING TO CONSOLE M 14X35
999
SCREW , Replaced By: N308676014008
999
GUSSET PLATE REAR CROSS MEMBER,RIGHT
999
GUSSET PLATE REAR CROSS MEMBER,LEFT
999
CROSS MEMBER (REAR CROSS MEMBER)
999
GUSSET PLATE RIGHT,ZAN 3725/85 N1
999
GUSSET PLATE LEFT,ZAN 3725/85 N1
999
CROSS MEMBER (REAR CROSS MEMBER),ZAN 3725/85 N1
999
FRAME , UP TO IDENT NO. 5 025411 EXCEPT FOR 5 022764,5 023094,5 023152,5 023194,5 023364,5 023395,5 023475,5 023522,5 023549,5 023744,5 023802,5 023818,5 023852,5 023985, 5 024133,5 024169,5 024185,5 024195,5 024585,5 024645,5 024660,5 024964,5 025014,5 025045,5 025054,5 025095,5 025131,5 025221., Replaced By: A6213108301, +002A6202400006, +006N000961016011
999
HELPER SPRING BRACKET , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A3893250117
999
RUBBER BUFFER , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A3893250117
999
MOUNTING , Replaced By: A3878913220
999
CONSOLE , Replaced By: A6208910731
999
CONSOLE , Replaced By: A6208910631
999
SHIM , Replaced By: A3878910498
999
REPAIR KIT , Replaced By: A3879920003, +002A6208910017, +001A3638910023
999
REPAIR KIT , Replaced By: A3873100077
999
STRUT , Replaced By: A3873100353
999
STRUT , Replaced By: A6203121561
999
RIVET BUSHING AND LEVER TO CAB
999
PIN PULL TO FASTENER
999
JOINT BEARING
999
JOINT BEARING , Replaced By: A0009817231
