Поз.
Артикул
Описание
24
GROMMET BATTERY CASE
24
GROMMET BATTERY CASE
45
COVER BATTERY/APPARATUS SUPPORT
48
POSITIVE CABLE FROM BATTERY POS. POLE TO CABLE CONNECTOR,5 193595
48
ELECTRIC CABLE , Replaced By: A6205400230
48
POSITIVE CABLE FROM BATTERY POS.POLE TO STARTING MOTOR,5 129698
48
POSITIVE CABLE FROM BATTERY POS.POLE TO STARTING MOTOR,5 129698
48
POSITIVE CABLE ,5 193595, Replaced By: A6205402530
48
POSITIVE CABLE , Replaced By: A6205402530
48
POSITIVE CABLE FROM CABLE CONNECTOR TO STARTING MOTOR
48
POSITIVE CABLE FROM BATTERY POS.POLE TO STARTING MOTOR,5 1296995 193594
48
POSITIVE CABLE FROM BATTERY POS.POLE TO STARTING MOTOR
48
POSITIVE CABLE FROM BATTERY POS.POLE TO STARTING MOTOR,5 1296995 193594
48
POSITIVE CABLE FROM BATTERY POS.POLE TO STARTING MOTOR,5 1296995 193594
48
POSITIVE CABLE FROM BATTERY POS. POLE TO CABLE CONNECTOR,5 193595
48
POSITIVE CABLE FROM BATTERY POS.POLE TO STARTING MOTOR,5 1296995 193594
48
POSITIVE CABLE ,5 193595, Replaced By: A6205402530
48
POSITIVE CABLE FROM CABLE CONNECTOR TO STARTING MOTOR
48
POSITIVE CABLE , Replaced By: A6205402530
48
POSITIVE CABLE FROM BATTERY POS.POLE TO STARTING MOTOR,5 1296995 193594
48
POSITIVE CABLE , Replaced By: A6205402530
48
POSITIVE CABLE FROM BATTERY POS.POLE TO STARTING MOTOR,5 1296995 193594
48
POSITIVE CABLE FROM BATTERY POS.POLE TO STARTING MOTOR
50
BRACKET FROM CABLE CONNECTOR TO STARTING MOTOR POLE +,5 193595
50
BRACKET FROM CABLE CONNECTOR TO STARTING MOTOR POLE +,5 193595
52
CONNECTOR BATTERY CABLE CONNECTOR
52
CONNECTOR BATTERY CABLE CONNECTOR
54
SCREW BATTERY CABLE MOUNTING,5 193595
54
SCREW BATTERY CABLE MOUNTING,5 193595
54
SCREW BATTERY CABLE MOUNTING,5 193595
56
SCREW , Replaced By: A0029903712
56
SCREW , Replaced By: N000000001149
56
HEXALOBULAR BOLT WIRE CABLE TO BRACKET
56
HEXALOBULAR BOLT WIRE CABLE TO BRACKET
56
HEXALOBULAR BOLT WIRE CABLE TO BRACKET
58
WASHER , Replaced By: N000125010532
58
WASHER RADIATOR TO RUBBER MOUNTING
58
WASHER RADIATOR TO RUBBER MOUNTING
60
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
60
WASHER COMPRESSED AIR LINE TO BRACKET
60
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
60
WASHER COMPRESSED AIR LINE TO BRACKET
62
NUT , Replaced By: N304035010001
62
NUT
62
NUT
64
NUT BATTERY CABLE TO CABLE CONNECTOR,5 193595
64
NUT BATTERY CABLE MOUNTING,5 193595
64
NUT BATTERY CABLE MOUNTING,5 193595
68
CAP CONNECTOR,5 193595
68
CAP CONNECTOR,5 193595
76
BRACKET BATTERY CABLE TO BELL HOUSING
76
BRACKET BATTERY CABLE TO BELL HOUSING
76
BRACKET BATTERY CABLE TO BELL HOUSING,5 193595
76
BRACKET BATTERY CABLE TO BELL HOUSING,5 193595
78
BRACKET BATTERY CABLE TO BELL HOUSING,5 193595
78
BRACKET BATTERY CABLE TO BELL HOUSING,5 193595
80
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
80
WASHER COMPRESSED AIR LINE TO BRACKET
80
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
80
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
80
WASHER COMPRESSED AIR LINE TO BRACKET
82
SCREW , Replaced By: A0029903712
82
HEXALOBULAR BOLT WIRE CABLE TO BRACKET
82
SCREW , Replaced By: N000000001149
82
HEXALOBULAR BOLT WIRE CABLE TO BRACKET
82
HEXALOBULAR BOLT WIRE CABLE TO BRACKET
84
NUT , Replaced By: N304035010001
84
NUT
84
NUT
86
NUT BATTERY CABLE TO CABLE CONNECTOR,5 193595
86
NUT BATTERY CABLE MOUNTING,5 193595
86
NUT BATTERY CABLE TO CABLE CONNECTOR,5 193595
86
NUT BATTERY CABLE MOUNTING,5 193595
88
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
88
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
90
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
90
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
92
ELECTRIC CABLE , Replaced By: N072551070880, +001A6205460035, +001A1115460071, +001N046234010007, +001N072332013200
92
ELECTRIC CABLE , Replaced By: N922002070000
92
ELECTRIC CABLE , Replaced By: A6735460013
92
ELECTRIC CABLE FROM BATTERY POS.POLE TO STARTING MOTOR 70 MM2, ORDER BY THE METER
94
SCREW NEG.POLE
96
BOOT NEG. CABLE
98
NEG. CABLE , Replaced By: A6205400831
98
NEG. CABLE , Replaced By: A6205401831, +001A0005468730
98
NEG. CABLE FROM BATTERY MASTER SWITCH NEG.POLE TO STARTING MOTOR NEG.POLE,5 193594
98
NEG. CABLE FROM BATTERY MASTER SWITCH NEG.POLE TO STARTING MOTOR NEG.POLE,5 193594
98
ELECTRIC CABLE FROM BATTERY MASTER SWITCH TO GROUND AT FRAME SIDE MEMBER,5 193595
98
NEG. CABLE , Replaced By: A6205401831
98
NEG. CABLE FROM BATTERY MASTER SWITCH NEG.POLE TO STARTING MOTOR NEG.POLE,5 193594
98
NEG. CABLE , Replaced By: A6205401831, +001A0005468730
98
NEG. CABLE FROM BATTERY MASTER SWITCH NEG.POLE TO STARTING MOTOR NEG.POLE,5 193594
98
NEG. CABLE , Replaced By: A6205400831
100
BOOT NEG. CABLE
102
GROUND STRAP FROM STARTING MOTOR TO SIDE MEMBER,5 193595
102
GROUND STRAP FROM STARTING MOTOR TO SIDE MEMBER,5 193595
102
GROUND STRAP , Replaced By: A3525400041
102
GROUND STRAP FROM STARTING MOTOR TO SIDE MEMBER
102
GROUND STRAP FROM STARTING MOTOR TO SIDE MEMBER
102
GROUND STRAP , Replaced By: A3145460320
106
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
106
BRACKET , Replaced By: A6205244040
108
SCREW PIPE CLAMP
108
SCREW , Replaced By: N304017008021
110
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
110
NUT , Replaced By: N913004008001
112
CLAMPING PIECE BATTERY CABLE MOUNTING
112
CLAMPING PIECE BATTERY CABLE MOUNTING
114
SCREW DISTRIBUTOR TO CAB
116
WASHER COMPRESSED AIR LINE TO BRACKET
116
WASHER , Replaced By: N009021006208
118
BRACKET BATTERY CABLE MOUNTING,5 193595
118
BRACKET BATTERY CABLE MOUNTING,5 193595
118
BRACKET , Replaced By: A3854290540
120
BRACKET LINE MOUNTING
120
BRACKET LINE MOUNTING
120
BRACKET , Replaced By: A3184280240
122
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
122
SCREW , Replaced By: N304017008027
122
SCREW SUPPORT TO FENDER
122
SCREW SUPPORT TO FENDER
122
SCREW SUPPORT TO FENDER
122
SCREW , Replaced By: N304017008018
124
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
124
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
124
NUT , Replaced By: N913004008001
125
CLAMP BATTERY CABLE TO FRAME SIDE MEMBER NEAR TRANSMISSION
128
CLAMPING PIECE BATTERY CABLE MOUNTING
128
CLAMPING PIECE BATTERY CABLE MOUNTING
128
CLAMPING PIECE BATTERY CABLE MOUNTING
128
CLAMPING PIECE BATTERY CABLE MOUNTING
129
CLAMP BATTERY CABLE MOUNTING AND MAIN CABLE HARNESS MOUNTING,5 579088
129
CLAMP , Replaced By: A0005462675
131
SPACER TUBE ELECTRIC CABLE TO FRAME SIDE MEMBER
133
SCREW BRACKET TO CROSS MEMBER
133
SCREW , Replaced By: N304014006004
136
SCREW , Replaced By: N304017006026
136
SCREW DISTRIBUTOR TO CAB
136
SCREW , Replaced By: N304017006026
136
SCREW , Replaced By: N304017006026
136
SCREW DISTRIBUTOR TO CAB
136
SCREW DISTRIBUTOR TO CAB
137
SCREW , Replaced By: N304017006026
137
SCREW , Replaced By: N304017006026
140
WASHER COMPRESSED AIR LINE TO BRACKET
140
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
140
WASHER COMPRESSED AIR LINE TO BRACKET
140
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
142
NUT , Replaced By: N913004006001
142
NUT PUMP TO BRACKET
142
NUT PUMP TO BRACKET
158
GROMMET BATTERY CASE
999
EMERGENCY LANTERN
999
EDGE GUARD SECTION , ORDER BY THE METER
999
NUT PRESSURE SWITCH SCREW-CONNECTION M 24X1,5 129167
999
WASHER PRESSURE SWITCH SCREW-CONNECTION TO M 24X1,5 129167
999
CABLE CONNECTOR , Replaced By: A0015465441, +001A0009872844
999
LOOM TIE LINE MOUNTING 280 MM
999
PLUG CONNECTION POINT BEHIND REAR AXLE
999
PLUG REAR CABLE CONNECTOR,5 180266
999
BRACKET CABLE CONNECTOR
999
BOOT PRESSURE SWITCH SCREW-CONNECTION TO M 27X1, M 24X1
999
BRACKET ELECTRIC CABLE MOUNTING
999
BRACKET FRAME MOUNTED CABLE HARNESS AND BATTERY CABLE TO BELL HOUSING
999
LOCK INSULATING HOSE
999
CLAMPING PIECE , Replaced By: A3635460044
999
CAP CABLE CONNECTOR TO 6205400074, NOT USED
999
GROMMET LINE MOUNTING 50/45 MM
999
BRACKET LINES TO ENGINE
999
BRACKET BATTERY CABLE TO CROSS MEMBER
999
BRACKET BATTERY CABLE TO CROSS MEMBER
999
BRACKET FRAME MOUNTED CABLE HARNESS AND BATTERY CABLE TO BELL HOUSING
