Поз.
Артикул
Описание
114
HOUSING BELL HOUSING WITH BUSHINGS
114
HOUSING , Replaced By: A4032505405, +001A6202500155
118
BUSHING RELEASE SHAFT,BOTTOM
122
BUSHING RELEASE SHAFT,BOTTOM 24X27 MM
126
BUSHING RELEASE SHAFT,TOP
126
BUSHING ,5 285575, Replaced By: A6202510050, +001A6202500155, +001A0099971547
130
BUSHING RELEASE SHAFT,TOP 35X39 MM
134
SEAL RING RELEASE SHAFT,TOP
136
SEAL RING RELEASE SHAFT,TOP 40X52X7 MM
138
COVER PLATE RELEASE SHAFT,TOP
142
PLUG BELL HOUSING
142
PLUG BELL HOUSING
146
SHAFT (PARTS KIT),RELEASE SHAFT
146
SHAFT , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 285575, Replaced By: A3852500014
146
REPAIR KIT , Replaced By: A3892500014
150
WASHER AS REQUIRED 1.3 MM
150
WASHER AS REQUIRED 1.20 MM
150
WASHER AS REQUIRED 1.10 MM
150
WASHER AS REQUIRED 1.00 MM
150
WASHER AS REQUIRED 0.90 MM
150
WASHER AS REQUIRED 0.80 MM
154
SEAL RING BOTTOM
158
SPACER WASHER RELEASE SHAFT,BOTTOM
162
LOCK RING RELEASE SHAFT,BOTTOM
166
RELEASE LEVER CLUTCH ACTUATION
166
RELEASE LEVER , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 758189, Replaced By: A6202540108
170
LOCK WASHER FITTING TO BRACKET
174
SCREW RELEASE LEVER TO SHAFT
174
SCREW , Replaced By: N304017012018
174
SCREW , Replaced By: N000933012102
178
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
182
SCREW RADIATOR M 10X45
190
RELEASE BEARING CLUTCH
194
SPRING RELEASE BEARING TO RELEASE LEVER
202
HOSE RELEASE COLLAR LUBRICATION 220 MM
204
GREASE NIPPLE (PARTS KIT) RELEASE BEARING LUBRICATION
205
SCREW-IN FITTING RELEASE COLLAR LUBRICATION
206
UNION SCREW RELEASE COLLAR LUBRICATION
210
DOUBLE TAPER RING RELEASE COLLAR LUBRICATION
222
GREASE NIPPLE RELEASE COLLAR LUBRICATION
222
INTERMEDIATE PIECE ,5 190179, Replaced By: A6209970088, +001A6209880135
224
CAP RELEASE BEARING LUBRICATION
224
GREASE CUP ,5 190179, Replaced By: A6209880135, +001A6209970088
226
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
228
NUT RELEASE BEARING LUBRICATION
228
NUT , Replaced By: N308675014002
228
NUT , Replaced By: N308675014000
230
LEVER (PARTS KIT),CLUTCH ACTUATION
234
ROD END CLUTCH ACTUATION
238
PIN CLUTCH ACTUATION
242
SEAL RING CLUTCH ACTUATION
242
SEAL RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0019972141
246
LOCK RINGTO 000 553 37 01,000 553 39 01,
250
COVER RELEASE SHAFT,TOP
250
WASHER LEVER TO RELEASE SHAFT,5 285575
250
WASHER , Replaced By: A6202540176
254
SEAL RING LEVER TO RELEASE SHAFT,5 285575
258
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
262
SCREW MOUNTING AND RAIL TO LEAF SPRING
280
BRACKET CLUTCH ACTUATION
282
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
286
SCREW BRACKET TO SIDE MEMBER
286
SCREW , Replaced By: N304017010002
292
SLAVE CYLINDER CLUTCH ACTUATION KONGSBERG
292
SLAVE CYLINDER CLUTCH ACTUATION WABCO, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
292
SLAVE CYLINDER , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0012956707
292
SLAVE CYLINDER CLUTCH ACTUATION KNORR
295
BOOTWABCO
296
BOOTWABCO
307
REPAIR KIT , NOT USED
308
SEAL RING. REPAIR KIT CLUTCH SLAVE CYLINDER WABCO
308
REPAIR KIT CLUTCH SLAVE CYLINDER TO 001 295 31 07,WABCO 970 051 113 0
312
SPRING WASHER STEERING COLUMN BRACKET TO CAB
314
SCREW CLUTCH BOOSTER TO BELL HOUSING M 10X30,5 962907
314
SCREW , Replaced By: N914146010114
318
LOCK WASHER BELL HOUSING TO TRANSMISSION
322
SCREW SUPPORTING ARM TO CYLINDER CRANKCASE M 18X60
322
SCREW , Replaced By: N308676018010
999
CLUTCH BOOSTER. REPAIR KIT CLUTCH SLAVE CYLINDER KONGSBERG
999
BOOTKONGSBERG
999
BOOTKONGSBERG
999
SHAFT , NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT, Replaced By: A3895860025
999
LEVER , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE5 388425, Replaced By: A6242950028, +001A6242950140
999
WASHER , Replaced By: N000125010532
999
WASHER RADIATOR TO RUBBER MOUNTING
