Поз.
Артикул
Описание
10
CONNECTOR HOSE WIDTH, / I.D., 6 MM
20
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
30
CONNECTOR DISTRIBUTOR TO CAB
40
SEAL RING
50
CONNECTOR DISTRIBUTOR TO CAB
50
CONNECTOR DISTRIBUTOR TO CAB
60
SEAL RING
70
CONNECTOR HOSE WIDTH, 6 MM, TO M22
80
ELBOW FITTING , Replaced By: A0049905371
80
ELBOW FITTING HOSE WIDTH, 6 MM,TO M22
80
ELBOW FITTING HOSE WIDTH, 9 MM,TO M22
90
ELBOW FITTING. T-FITTING LINE CONNECTION TO ENGINE TO M16
100
UNION NUT
110
SEAL CONE
110
GLAND , Replaced By: A0019901667
120
T-FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION
130
BANJO UNION HOSE WIDTH, / I.D., 6/10 MM
140
CONNECTOR COMPRESSED-AIR-LINE PLUG-CONNECTION
150
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
160
CONNECTOR COMPRESSED-AIR-LINE PLUG-CONNECTION
170
SEAL RING
180
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 16
190
ELBOW FITTING
200
UNION NUT
210
SEAL CONE
210
GLAND , Replaced By: A0019901667
220
BANJO UNION HOSE WIDTH, / I.D., 4/12 MM
230
LOCK RING LINE CONNECTION
230
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
230
SEAL RING , Replaced By: A0009940747
240
LOCK , Replaced By: A0009945448
240
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
240
LOCK LINE CONNECTION
250
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION
260
ELBOW FITTING HOSE WIDTH, 9 MM,TO M 22
270
T-FITTING
280
TANK RECESS. T-FITTING LINE CONNECTION
290
SCREW. UNION SCREW LINE CONNECTION
300
NUT CHECK VALVE TO AIR RESERVOIR
310
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
310
THRUST RING CHECK VALVE TO AIR RESERVOIR
320
O-RING CHECK VALVE TO AIR RESERVOIR
330
FITTING , Replaced By: A0019972372
340
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
350
VALVE 3/2-WAY,EMERGENCY RELEASE, ON ENGINE SUPPORT
360
HANDLE 3/2-WAY VALVE TO BRACKET
370
NUT 4/3-WAY VALVE TO SUBSTRUCTURE
380
VALVE (3/2-WAY SOLENOID VALVE), PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
390
SEAL RINGWABCO
400
SEAL RINGWABCO
410
SEAL RINGWABCO
420
VALVE PART
430
SCREW 3/2-WAY VALVE TO BRACKET M 8X105
440
VALVE. SHUTTLE VALVE (SHUTTLE VALVE) VOSS
440
VALVE. SHUTTLE VALVE (SHUTTLE VALVE) VOSS
440
VALVE , Replaced By: A0044291544
450
SCREW. UNION SCREW , Replaced By: A0009973734
450
SCREW. UNION SCREW LINE CONNECTION
460
HOLLOW SCREW HEATING CONNECTION
470
SEAL RING LINE CONNECTION
480
HOLLOW SCREW LINE CONNECTION
490
SEAL RING LINE CONNECTION
500
PIPE SOCKET COMPRESSED AIR PIPING TO 3/2-WAY VALVE
510
SCREW SHUTTLE VALVE,CONNECTIONS: "11,12"
520
SEAL RINGBOSCH
530
GUIDE SIGN
