Mercedes N304032008006 - ГАЙКА М8

O 530 LOW ENTRY 12M, 2-TUERER 628.583

32 SPRINGS AND SUSPENSION - 060 COMPRESSED AIR LINES,LEVEL ADJUSTMENT VALVES IL. 1

Поз.
Артикул
Описание
100
A6285403714
BATTERY CRADLE ASSEMBLY
100
A6285400414
BATTERY CASE (BASIC CARRIER)
100
A6285400514
BATTERY CASE ASSEMBLY
101
A6285403614
BATTERY CRADLE BASIC CARRIER
105
A6288901675
BATTERY CASE. BATTERY BOX TOP
110
A3057580151
HINGE BATTERY CASE TO FRAME, Replaced By: A6445410022
115
A6288950065
LEDGE BATTERY CASE TO FRAME
118
A0029900120
SCREWM6X20
118
N000000002027
TAPPING SCREW2,9X9,5
120
A6288900110
FIXTURE ROLLER
123
A0019909220
BOLT. SCREWM4X10 T20
126
N910105008039
SCREW , Replaced By: N910143008002
126
N910105006002
HEXAGON HEAD BOLT
126
N000000001875
HEXALOBULAR BOLT BRACKET TO SUPPORT M8X20
126
N000000006636
SCREW-AND-WASHER ASSEMBLYM6X20
128
N910112008000
HEXAGON NUT. NUT BRACKET TO CAB REAR PANEL
128
N304032008006
NUT
130
A6288900822
RAIL BATTERY MOUNTING
135
A6285402618
TENSIONING RAIL WITH BRACKET
135
A6288951470
RAIL BATTERY MOUNTING
136
A3016020014
BRACKET
140
A3058950064
CLAMPING RAIL ,086410
145
A6288950553
BASE UNDER BATTERY CASE
150
A6288950309
COVERING UNDER BATTERY CASE
155
A6288950292
SLIDE
158
A6288950092
SLIDE
160
A6288952714
BRACKET
165
A6288950379
HOOK
170
A6289900013
THREADED PINM8
175
A6288950117
ROLLER
180
A0009913101
PIN11X32X28MM
185
N000094001616
COTTER PIN ,SB044945
185
N000094001617
COTTER PIN BRACKET TO BATTERY CASE, 415 5 014668 416 5 000515 417 4 972023
