Поз.
Артикул
Описание
8
PLASTIC PIPE AERATION, ORDER BY THE METER
11
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
14
HOSE DELIVERY LINE TO POWER CYLINDER
17
VALVE , Replaced By: A0044293144
23
VALVE (3/2-WAY SOLENOID VALVE) ENGINE SHUT-OFF EKS, REPAIR IMPOSSIBLE
23
SOLENOID VALVE (3/2-WAY SOLENOID VALVE)
23
3-2-WAY PNEUMATIC VALVE (3/2-WAY SOLENOID VALVE)
26
SCREWM6X12 TX30
26
SCREW BRACKET TO COVERING
29
SEAL RINGBOSCH
32
REDUCTION FITTINGM14X1.5/M12X1.5
32
FITTING PARKING BRAKE VALVE,CONNECTION: "23"
38
FITTINGM12X1.5/M14X1.5
41
SEAL RING RIGHT SPRING-LOAD ACCUMULATOR 10X2.2
47
RESERVOIR
47
RESERVOIR , Replaced By: A0004300503
50
VALVE DRAIN VALVE
53
THRUST RING CHECK VALVE TO AIR RESERVOIR
56
SEAL RING20.3X2.4
59
HEXAGON HEAD BOLT. SCREW FRONT EXHAUST PIPE TO BRACKET
62
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
65
HEXALOBULAR BOLT SOLENOID VALVE TO BRACKET M8X100
65
HEXAGON HEAD BOLT. SCREW 3/2-WAY VALVE TO BRACKET M 8X100
68
NUT HORN TO BRACKET M8
68
HEXAGON NUT. NUT BRACKET TO CAB REAR PANEL
68
NUT ENGINE MOUNTING M8
71
CLAMP LINE MOUNTING 8/15
71
CLAMP10/15
71
CLAMP
71
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
74
SCREW BRACKET AND CLAMP M6X20
74
HEXALOBULAR BOLT GROUND CABLE TO GENERATOR M6X20
77
NUT , Replaced By: N913023006001
77
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
77
NUT BRACKET TO FIRE WALL
86
BRACKET
89
BRACKET , Replaced By: A0004340240
89
BRACKET
92
SCREW PIPE ELBOW TO BRACKET M8X12
92
SCREW SPEED SENSOR TO REAR AXLE
412
GLAND
412
CUTTING RINGBS8
415
UNION NUT
415
NUTM 14 X 1,5AL
454
HOSE
457
LOOM TIE LINE MOUNTING 150 X 3,6 MM
472
PIPE8MM
475
PIPE8MM
