Поз.
Артикул
Описание
35
HOSE FEED AND RETURN LINE CONNECTION, LENGTH AVAILABLE 1000 MM
53
INTAKE PIPE SOCKET RETURN LINE TO RADIATOR
53
INTAKE PIPE SOCKET
56
GASKET OUTLET TO ENGINE
59
SCREW FLEXIBLE METAL TUBE TO CONNECTOR AND TO COLLAR
59
SCREW , Replaced By: N304017008028
62
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
62
SPRING WASHER , Replaced By: N000137008212
65
LINE RETURN LINE
65
LINE RETURN
65
LINE RETURN LINE
71
LINE RETURN
71
LINE RETURN
74
SCREW PLUGROCKINGER,TYP 59 U150
74
SCREW PLUGROCKINGER TYP 59 G140,59 G150, Replaced By: N007604012105
77
SEAL RING PRESSURE REGULATOR,CONNECTION: "23",5 161701
80
COOLING WATER LINE RETURN
83
LINE RETURN LINE
83
LINE RETURN LINE
86
HOSE FEED AND RETURN LINE CONNECTION
89
HOSE FEED AND RETURN LINE CONNECTION
92
SCREW PLUG, FILLING OIL COOLER
95
SEAL RING CLUTCH BOOSTER
98
BRACKET FUEL LINES TO TRANSMISSION
101
HOSE BRAKE VALVE,CONNECTION: "30"
101
HOSE DE-AERATION LINE, ORDER BY THE METER
101
HOSE DE-AERATION LINE, ORDER BY THE METER, Replaced By: A9575011982
101
HOSE , Replaced By: A0805013482
104
HOSE CLAMP LINE MOUNTING
104
CLAMP , Replaced By: A0059970190
104
CLAMP , Replaced By: A1409950036
107
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
110
HOLLOW SCREW LINE CONNECTION
113
HOLLOW SCREW HEATING CONNECTION
116
SEAL RING CHECK VALVE,CONNECTION "1",4 704213
119
HOSE CLAMP LINE MOUNTING
119
CLAMP , Replaced By: A0059970190
119
CLAMP HOSE TO FITTING AND TO OIL TANK
122
BANJO UNION DE-AERATION LINE TO COOLING WATER LINE
125
HOLLOW SCREW FUEL LINE TO FEED PUMP
125
HOLLOW SCREW , Replaced By: N915036010108
128
SEALING RING. SEAL RING ENGINE BREATHING
999
LINE RETURN, ENGINE
999
BRACKET BRACKET TO PULL ROD
999
BRACKET LINE MOUNTING
