Поз.
Артикул
Описание
5
WIRE CABLE MANUAL CONTROL
5
WIRE CABLE MANUAL CONTROL, REPAIR IMPOSSIBLE
5
WIRE CABLE MANUAL CONTROL, REPAIR IMPOSSIBLE
8
FITTED WASHER WIRE CABLE TO INSTRUMENT PANEL
11
NUT WIRE CABLE TO INSTRUMENT PANEL
14
KNOB IDLING ADJUSTMENT
17
CLAMPING PIECE IDLING ADJUSTMENT WIRE CABLE
18
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
18
CLAMP ,K 147121, Replaced By: N000000000319
20
SCREW , Replaced By: N000000001149
20
SCREW , Replaced By: A0029903712
20
HEXALOBULAR BOLT WIRE CABLE TO BRACKET
23
WASHER COMPRESSED AIR LINE TO BRACKET
23
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
26
NUT , Replaced By: N913004006001
26
NUT PUMP TO BRACKET
27
BRACKET WIRE CABLE TO AIR BAFFLE BRACKET
38
BRACKET WIRE CABLE TO FRAME SIDE MEMBER
38
BRACKET WIRE CABLE TO STEERING OIL TANK BRACKET
41
BRACKET WIRE CABLE TO STEERING OIL TANK BRACKET
47
BRACKET WIRE CABLE TO BRACKET
47
BRACKET , Replaced By: A6523011940
53
BRACKET WIRE CABLE TO HYDRAULIC LINE BRACKET
59
SCREW END PIECE TO EXHAUST PIPE M 10X25
62
NUT , Replaced By: N910113010000
62
NUT STRAP TO BRACKET
65
SCREW CENTRAL LOCK TO CAB M 10X16
65
SCREW LICENSE PLATE TO BRACKET
65
SCREW , Replaced By: N304017006020
65
SCREW PUMP TO BRACKET
68
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
68
WASHER COMPRESSED AIR LINE TO BRACKET
71
NUT PUMP TO BRACKET
71
NUT , Replaced By: N913004006001
74
LOOM TIE LINE MOUNTING
74
LOOM TIE LINE MOUNTING 280 MM
80
CLAMPING PIECE IDLING ADJUSTMENT WIRE CABLE
81
CLAMP ,K 147121, Replaced By: N000000000319
81
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
83
HEXALOBULAR BOLT WIRE CABLE TO BRACKET
83
SCREW , Replaced By: N000000001149
83
SCREW , Replaced By: A0029903712
86
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
86
WASHER COMPRESSED AIR LINE TO BRACKET
89
NUT PUMP TO BRACKET
89
NUT , Replaced By: N913004006001
