Поз.
Артикул
Описание
5
SUPPORTING ARM RIGHT, TO BE ADAPTED DURING ASSEMBLY
5
SUPPORTING ARM LEFT, TO BE ADAPTED DURING ASSEMBLY
7
BUSHING21,8X16,5X22
8
SCREW , Replaced By: N308676018001
11
RUBBER MOUNTING REAR
11
RUBBER MOUNTING REAR
11
RUBBER MOUNTING ON CLUTCH END
11
RUBBER MOUNTING REAR
11
RUBBER MOUNTING ON CLUTCH END
14
BRACKET ENGINE MOUNTING
17
SCREW , Replaced By: N308676016005
17
SCREW TRAILER COUPLING TO REAR CROSS MEMBER
20
WASHER CONSOLE TO FRAME
23
SCREENING PLATE REAR RUBBER MOUNTING
26
SCREW SUPPORT TO SIDE MEMBER M 12X1.5X30
29
WASHER SUPPORT TO FRAME,D 127794
32
ENGINE VIBRATION ABSORBER REAR
35
RUBBER BUFFERTO 682 317 71 03
38
BUSHINGTO 682 317 71 03
41
SCREW STEERING SUPPORT TO FRAME M 12X1,5X50
44
SCREW ALTERNATOR TO SUPPORT
47
WASHER SUPPORT TO FRAME,D 127794
50
WASHER
50
WASHER
50
WASHER
53
NUT ALTERNATOR TO SUPPORT
56
BRACKET ENGINE ALONGSIDE FIXING
59
SCREW BATTERY CASE TO SIDE MEMBER
62
SHIM
65
NUT PROPELLER SHAFT TO TRANSMISSION
68
ROD ENGINE ALONGSIDE FIXING
71
ROD END LEFT TO 364 240 76 25
71
ROD END RIGHT TO 364 240 76 25
74
CLAMPTO 364 240 76 25
77
SCREW CLAMP TO DRAG LINK TO 344 338 73 45
80
NUT , Replaced By: N910113010002
83
BRACKET SHOCK ABSORBER TO BRACKET
83
BRACKET , Replaced By: A6642427340
86
STUD PULL ROD TO BEARING BRACKET
89
NUT FRONT SPRING TO FRONT SPRING FRONT AND REAR BRACKETS
