Поз.
Артикул
Описание
29
FILLER NECK FUEL SYSTEM
29
FILLER NECK FUEL SYSTEM
29
FILLER NECK , Replaced By: A6674702520
29
FILLER NECK , Replaced By: A6674702620
29
FILLER NECK , Replaced By: A6674704420
29
FILLER NECK , Replaced By: A6674704520
29
FILLER NECK FUEL SYSTEM
35
FILLER NECK FUEL SYSTEM
35
FILLER NECK , Replaced By: A6674701720
37
SCREW PLUG , Replaced By: A2109970132
37
SCREW PLUG
39
SEALING RING. SEAL RING OIL DRAIN
41
FILLER NECK CONNECTION OF FUEL TANKS
41
FILLER NECK CONNECTION OF FUEL TANKS
41
LINE , Replaced By: A6674701520
41
LINE , Replaced By: A6674701620
53
BRACKET , Replaced By: A6674760337
53
BRACKET CONNECTING PIPE TO WOOD FLOOR
59
SCREW COVERING
65
LOCK WASHER WIRE CABLE TO LEVER
71
NUT SPRING-LOADED PUSH ROD
107
HOSE FILLER NECK TO FUEL TANK
113
HOSE , Replaced By: A6674711282
113
HOSE FILLER NECK TO FUEL TANK
119
HOSE , Replaced By: A6674711182
119
HOSE FILLER NECK TO FUEL TANK
125
HOSE FILLER NECK TO FUEL TANK
125
HOSE FILLER NECK TO FUEL TANK
143
CLAMP , Replaced By: N000000000672
143
CLAMP HOSE FASTENING 50-70X13 MM
180
BUFFER
185
WASHER BRACKET TO LEFT SIDE MEMBER
185
WASHER , Replaced By: N009021008213
188
SPRING WASHER , Replaced By: N000137008212
188
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
191
NUT STRAP TO BRACKET
195
RIVETED NUT BATTERY CHANGE-OVER SWITCH
249
COVER , Replaced By: A6674700032
249
COLLECTING PAN
378
CLAMP
395
LINE FILLER NECK TO LINE, 961992 N 000000 P 000000
395
HOSE FILLER NECK TO LINE, 961993 N 000001 P 000001
401
CLAMP SUCTION LINE TO OIL PUMP 40-60X13 MM
401
CLAMP , Replaced By: N000000000671
999
LINE FROM FUEL TANK TO FILLER NECK, 961992 N 000000 P 000000
