Поз.
Артикул
Описание
65
PARABOLIC CONTROL ARM , PLAESE REFER TO NOTE IN FDOK ONLY REPLACEABLE BY PAIRS, Replaced By: A6743500706
65
PARABOLIC CONTROL ARM
65
PARABOLIC CONTROL ARM
68
SPRING BOLT
68
SPRING BOLT ,5 227450
71
SHIM BETWEEN THE SPRING LEAVES, TO BE ADAPTED DURING ASSEMBLY
71
SHIM BETWEEN THE SPRING LEAVES, TO BE ADAPTED DURING ASSEMBLY
71
SHIM BETWEEN THE SPRING LEAVES, TO BE ADAPTED DURING ASSEMBLY
71
SHIM , Replaced By: A9703210184
71
SHIM , Replaced By: A9703210184
74
NUT , Replaced By: N910113012005
74
HEXAGON NUT. NUT SPRING BOLT
77
BUSHING SPRING EYE,FRONT
77
BUSHING SPRING EYE,REAR,5 905404
77
BUSHING SPRING EYE,REAR
80
RUBBER BUFFER BETWEEN THE SPRING EYES
83
SPRING CLAMP ,5 940410
86
RIVET SPRING CLAMP TO SPRING LEAF
89
SPACER TUBE SPRING CLAMP
92
SCREW SPRING CLAMP,5 533057
95
NUT END PIECE TO EXHAUST PIPE
98
THRUST WASHER REAR SPRING TO REAR SPRING FRONT BRACKET
101
NUT , Replaced By: N910113018004
101
NUT INTERMEDIATE LEVER TO STEERING SUPPORT
104
SHACKLE CONTROL ARM TO REAR SPRING REAR BRACKET,5 304390
104
SHACKLE , Replaced By: A6743200063, +001A3183200073
110
BEARING SHACKLE TO FRAME
113
SHACKLE (SPRING SHACKLE)
116
BUSHING REAR SPRING TO REAR SPRING REAR BRACKET
128
SCREW CONTROL ARM TO REAR SPRING REAR BRACKET
128
SCREW SHOCK ABSORBER TO CONSOLE
131
NUT TORSION BAR TO BEARING BRACKET,5 904661
134
SHIM CONTROL ARM TO REAR AXLE
134
SHIM CONTROL ARM TO REAR AXLE
134
SHIM REAR SPRING
134
SHIM CONTROL ARM TO REAR AXLE, HIGH END TO BE MOUNTED AT THE REAR WHEN VIEWED IN THE DIRECTION OF NORMAL TRAVEL5 2040435 328512
137
DOWEL PIN (CENTERING CONE),5 361887, Replaced By: A9303230574
137
DOWEL PIN , Replaced By: A6749910060
137
DOWEL PIN (CENTERING CONE),5 361886
137
CENTERING BOLT (CENTERING CONE),5 361887
164
BRACKET CONTROL ARM TO REAR AXLE, DISCONTINUED,PART IS NO LONGER REQUIRED
165
PLATE REAR SPRING TO REAR AXLE
166
U-BOLT FRONT SPRING TO FRONT AXLE,FRONT 300MM
167
SPHERICAL WASHER FRONT SPRINGS TO FRONT AXLE,5 468450
168
NUT FRONT SPRINGS TO FRONT AXLE
209
SHACKLE TORSION BAR MOUNTING
209
SHACKLE , Replaced By: A6743200363
215
SCREW , Replaced By: N000960016206
215
SCREW TRAILER COUPLING TO REAR CROSS MEMBER
218
NUT COMBINATION CYLINDER TO BEARING BRACKET
218
NUT COMBINATION CYLINDER TO BEARING BRACKET, Replaced By: N910113016002
999
SPACER TUBE TOP TO 005 326 55 00,5 711072
999
SCREW. UNION SCREW LINE CONNECTION
