Поз.
Артикул
Описание
1
LINE FROM DISTRIBUTOR TO VALVE 4200 MM,4 478330
1
LINE FROM DISTRIBUTOR TO VALVE 4800 MM
1
LINE FROM TEST CONNECTION TO BRAKE POWER REGULATOR 4000 MM,4 478329
1
LINE FROM CONNECTOR TO TEST CONNECTION 2800 MM,4 478330
1
LINE FROM CONNECTOR TO TEST CONNECTION 3400 MM,4 478330
1
LINE FROM TEST CONNECTION TO RIGHT FRONT WHEEL BRAKE HOSE
1
LINE FROM DISTRIBUTOR TO VALVE 3000 MM
19
BRAKE PRESSURE REGULATOR , UP TO CHASSIS 4 337020 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
19
BRAKE PRESSURE REGULATOR , UP TO CHASSIS 4 337020 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
19
BRAKE PRESSURE REGULATOR LOAD-DEPENDING BRAKE, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
19
BRAKE PRESSURE REGULATOR , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
19
BRAKE PRESSURE REGULATOR LOAD-DEPENDING BRAKE, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
28
VALVE PART
28
VALVE PART , Replaced By: A0004311068
28
VALVE PART
37
SPRING
37
SPRING
37
SPRING
46
SEAL RING VALVE TO VALVE,K 025179
46
SEAL RING VALVE TO VALVE,K 025179
55
VALVE , Replaced By: A0004310265
55
VALVE , Replaced By: A3075530107
55
VALVE CLUTCH SLAVE CYLINDER
55
VALVE CLUTCH SLAVE CYLINDER
59
ROD , Replaced By: N900331008427, +001A0004310667, +001A0004310867, +001N000934008010, +001N000934008035
59
ROD , Replaced By: N900331008427, +001A0004310667, +001A0004310867, +001N000934008010, +001N000934008035
59
ROD ,4 235128, Replaced By: N900331008427, +001A0004310667, +001A0004310867, +001N000934008010, +001N000934008035
59
ROD ,4 235128, Replaced By: N900331008427, +001A0004310667, +001A0004310867, +001N000934008010, +001N000934008035
59
ROD ,4 111961, Replaced By: N900331008426, +001A0004310667, +001A0004310867, +001N000934008010, +001N000934008035
59
ROD ,4 235128, Replaced By: N900331008427, +001A0004310667, +001A0004310867, +001N000934008010, +001N000934008035
59
ROD , 10/20 UP TO IDENT NO. 4 399151,50/60 UP TO IDENT NO. 4 416112, Replaced By: N900331008426, +001A0004310667, +001A0004310867, +001N000934008010, +001N000934008035
100
PULL ROD PNEUMATIC SUSPENSION CONTROL
100
PULL ROD PNEUMATIC SUSPENSION CONTROL
100
PULL ROD REAR AXLE SELF-LEVELLING DEVICE
100
PULL ROD PNEUMATIC SUSPENSION CONTROL
100
PULL ROD PNEUMATIC SUSPENSION CONTROL
109
YOKE , Replaced By: A0004310667
109
YOKE , Replaced By: A0004310467
109
YOKE L.H. THREAD, SELF-LEVELLING DEVICE
109
YOKE BOTTOM
118
NUT INTERMEDIATE SPEED STOP
118
NUT
119
SUPPORT BRAKE POWER REGULATOR
119
BRACKET , Replaced By: A3604300339
120
SCREW BRACKET TO SIDE MEMBER
120
SCREW , Replaced By: N304017010002
121
SCREW MOUNTING AND RAIL TO LEAF SPRING
122
NUT STRAP TO BRACKET
122
NUT , Replaced By: N910113010000
127
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
127
NUT , Replaced By: N913004008001
136
WASHER EXHAUST MUFFLER TO STRAP
136
WASHER , Replaced By: N000125008443
145
BRACKET OPERATING ROD,4 490322
145
BRACKET OPERATING ROD,4 490322
145
BRACKET OPERATING ROD,4 490322
154
SCREW SUPPORT TO CROSS MEMBER M 10X28
154
SCREW SUPPORT TO CROSS MEMBER M 10X28
163
SHIM BRACKET TO REAR AXLE HOUSING
163
SHIM BRACKET TO REAR AXLE HOUSING
163
SHIM BRACKET TO REAR AXLE HOUSING
181
WEB
181
WEB ,4 111961
181
WEB , Replaced By: A3184230125
190
SCREW PIPE CLAMP
190
SCREW PIPE CLAMP
190
SCREW , Replaced By: N304017008021
199
WASHER EXHAUST MUFFLER TO STRAP
199
WASHER , Replaced By: N000125008443
208
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
208
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
208
NUT , Replaced By: N913004008001
217
BRACKET ,4 111961
217
BRACKET , Replaced By: A3184200186
226
SCREW BRACKET TO SIDE MEMBER
226
SCREW , Replaced By: N304017010002
235
NUT AIR CLEANER ELEMENT
244
LEVER ,4 111961
244
LEVER , Replaced By: A3184200381
253
GREASE NIPPLE PROTECTIVE TUBE
262
PIN ,4 111961
262
PIN
271
LOCK RING PIN TO BEARING BRACKET, 380.017,080,081,180,181 ONLY FOR SHORT CAB MERCEDES-BENZ
280
LINE FROM DISTRIBUTOR TO BRAKE HOSE ON REAR AXLE 415 MM,4 478330
280
LINE FROM BRAKE POWER REGULATOR TO REAR BRAKE HOSE 500 MM
298
ROHRVERSCHRAUBUNG EM. UNION SCREW LINE MOUNTING
307
CLAMP , Replaced By: N916016008200
307
CLAMP ,K 147121, Replaced By: N000000000319
307
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
316
SCREW , Replaced By: N000000001146
316
SCREW CLAMP MOUNTING M 6X16
325
NUT , Replaced By: N913004006001
325
NUT PUMP TO BRACKET
334
TEST CONNECTION REAR AXLE BRAKE CIRCUIT
334
TEST CONNECTION REAR AXLE BRAKE CIRCUIT
343
BRACKET POS. CABLE,XB209706
343
BRACKET LINE MOUNTING
352
SCREW
361
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
361
WASHER COMPRESSED AIR LINE TO BRACKET
370
NUT , Replaced By: N913004006001
370
NUT PUMP TO BRACKET
379
SCREW , Replaced By: N304017010002
379
SCREW BRACKET TO SIDE MEMBER
379
SCREW END PIECE TO EXHAUST PIPE M 10X25
388
NUT , Replaced By: N910113010000
388
NUT STRAP TO BRACKET
397
LINE FROM MASTER CYLINDER TO CONNECTOR 285 MM, TO BE ADAPTED DURING ASSEMBLY
406
GUIDE SIGN LOAD-DEPENDING BRAKE
406
GUIDE SIGN LOAD-DEPENDING BRAKE
406
GUIDE SIGN
406
GUIDE SIGN LOAD-DEPENDING BRAKE
406
GUIDE SIGN LOAD-DEPENDING BRAKE
406
GUIDE SIGN LOAD-DEPENDING BRAKE
406
GUIDE SIGN LOAD-DEPENDING BRAKE
406
GUIDE SIGN LOAD-DEPENDING BRAKE
406
GUIDE SIGN LOAD-DEPENDING BRAKE
406
GUIDE SIGN LOAD-DEPENDING BRAKE
406
GUIDE SIGN LOAD-DEPENDING BRAKE
406
GUIDE SIGN LOAD-DEPENDING BRAKE
406
GUIDE SIGN LOAD-DEPENDING BRAKE
406
GUIDE SIGN LOAD-DEPENDING BRAKE,4 111961
406
GUIDE SIGN LOAD-DEPENDING BRAKE,4 111962
406
GUIDE SIGN LOAD-DEPENDING BRAKE
406
GUIDE SIGN LOAD-DEPENDING BRAKE,4 111961
406
GUIDE SIGN LOAD-DEPENDING BRAKE,4 111962
406
GUIDE SIGN LOAD-DEPENDING BRAKE
406
GUIDE SIGN LOAD-DEPENDING BRAKE
406
GUIDE SIGN LOAD-DEPENDING BRAKE
415
GUIDE SIGN ADJUSTMENT OF AUTOMATIC LOAD-DEPENDING BRAKE
415
GUIDE SIGN ADJUSTMENT OF AUTOMATIC LOAD-DEPENDING BRAKE
415
GUIDE SIGN ADJUSTMENT OF AUTOMATIC LOAD-DEPENDING BRAKE
415
GUIDE SIGN ADJUSTMENT OF AUTOMATIC LOAD-DEPENDING BRAKE
415
GUIDE SIGN ADJUSTMENT OF AUTOMATIC LOAD-DEPENDING BRAKE
415
GUIDE SIGN ADJUSTMENT OF AUTOMATIC LOAD-DEPENDING BRAKE
999
GUIDE BUSHINGTO 000 431 43 12,000 431 44 12
999
GUIDE BUSHING
999
LEVER TOOTHED
999
LEVER
999
LEVER TOOTHED
999
LEVER
999
GUIDE BUSHINGTO 000 431 43 12,000 431 44 12
999
PISTONTO 000 431 43 12,000 431 44 12
999
SEAL RINGTO 000 431 43 12,000 431 44 12
999
SEAL RING
999
FELT STRIPTO 000 431 43 12,000 431 44 12
999
SEAL RING BOTTOM RIGHT
999
SEAL RINGTO 000 431 44 12
999
SPRINGTO 000 431 46 12,001 431 12 12
999
SPRINGTO 000 431 46 12,001 431 12 12
999
SPRING BOTTOM RIGHT
999
SPRING
999
NEEDLE BEARINGTO 000 431 46 12,001 431 12 12
999
SEAL RINGTO 000 431 43 12,000 431 44 12, NO LONGER AVAILABLE
999
SEAL RING
999
ADHESIVE FOIL GUIDE SIGN
