Поз.
Артикул
Описание
5
THROTTLE HOUSING PARTS KIT,K 181318N 817421 - N 825202
5
THROTTLE HOUSING , Replaced By: A3661405353
8
VALVE PARTS KIT,K 181318N 817421 - N 825202
11
BUSHING
14
LEVER EXHAUST-BRAKE THROTTLE VALVE
14
LEVER , Replaced By: A3661400232, +001N913017006000, +001N914126006025
17
BALL PIVOT BOTTOM B13X5 MM
20
HEXALOBULAR BOLT. SCREW LINE MOUNTING M 6X30
20
SCREW , Replaced By: N000000001479
20
SCREW , Replaced By: N910105006005
20
SCREW LONGITUDINAL DIFFERENTIAL LOCK VALVE TO BRACKET,5 963747
23
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
23
NUT , Replaced By: N913023006001
23
NUT , Replaced By: N910112006001
23
NUT BALL PIVOT TO LEVER
26
WORKING CYLINDER (POWER CYLINDER),EXHAUST BRAKE
26
CYLINDER (POWER CYLINDER),EXHAUST BRAKE, Replaced By: A0004307926
26
CYLINDER , Replaced By: A0004305926
26
CYLINDER INTERMEDIATE SPEED STOP
26
CYLINDER , Replaced By: A0004304926
26
CYLINDER INCREASE IN NUMBER OF REVOLUTIONS KNORR
26
CYLINDER
29
BUSHING"WABCO"
29
BUSHINGTO 000 430 30 26/32 26
29
BUSHING , Replaced By: A0004340850
32
REPAIR KITTO 000 430 48 26,KNORR
32
REPAIR KIT SHIFTING CYLINDER TO KNORR, SZ 1130 I/74963,000 430 3026
38
NUT
38
NUT , Replaced By: N304035008001
41
BALL SOCKET SHIFTING CYLINDER TO SHIFT LEVER
41
BALL SOCKET
44
SECURING CLIP. CIRCLIP
47
PIN INTERMEDIATE SPEED STOP
47
PIN CYLINDER TO BRACKET
47
PIN , Replaced By: A4421440574
50
WASHER INTERMEDIATE SPEED STOP
50
WASHER EXHAUST MUFFLER TO STRAP
50
WASHER , Replaced By: N000125008443
53
NUT , Replaced By: N913004008001
56
WASHER
56
WASHER , Replaced By: N007349008007
59
NUT , Replaced By: N304032008006
62
BRACKET POWER CYLINDER, TO BE ADAPTED DURING ASSEMBLY
62
BRACKET , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. K 077169/N 817421 - 825202, Replaced By: A3661440440
65
SCREW BRACKET TO THROTTLE HOUSING M 8X16
68
SCREW BRACKET TO CONSOLE
68
SCREW , Replaced By: N000961012208
71
NUT THROTTLE HOUSING AND BRACKET TO FRONT EXHAUST PIPE
71
NUT , Replaced By: N910113012006
