Поз.
Артикул
Описание
37
HOSE , Replaced By: A0009872827
37
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
37
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
37
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
38
UNION NUT LINE CONNECTION, Replaced By: N000000006239
39
GLAND , Replaced By: A0019901967
39
SEAL CONE LINE CONNECTION
40
BUSHING , Replaced By: N915062009000
40
SLEEVE LINE CONNECTION
41
BANJO UNION HOSE WIDTH, / I.D., 9/16 MM
64
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
64
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
66
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
66
PLASTIC PIPE RISING PIPE 4X6 MM
66
PLASTIC PIPE RISING PIPE 4X6 MM
66
PLASTIC PIPE RISING PIPE 4X6 MM
68
UNION NUT
69
GLAND , Replaced By: A0019901667
69
SEAL CONE
70
BUSHING , Replaced By: N915062004000
70
SLEEVE LEAK LINE
72
BANJO UNION ,4 282708
73
LOOM TIE LINE MOUNTING 280 MM
90
VALVE , Replaced By: A0024310406
90
VALVE (FOUR-CIRCUIT PROTECTIVE VALVE) BOSCH, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
91
VALVE (FOUR-CIRCUIT PROTECTIVE VALVE) WABCO, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
92
VALVE , Replaced By: A0014318406
93
VALVE , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART, Replaced By: A0024312906
93
VALVE , Replaced By: A0024319306
93
VALVE (FOUR-CIRCUIT PROTECTIVE VALVE) GRAU, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
95
NUT CHECK VALVE TO AIR RESERVOIR
97
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
99
O-RING CHECK VALVE TO AIR RESERVOIR
101
ELBOW FITTING AIR RESERVOIR,CONNECTIONS: "31,32"
103
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
104
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
105
SEAL RING
105
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
106
ELBOW FITTING FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION "23" "23", 314.0.2 ALL, 316.0.2 ALL, 318.051-054 FROM IDENT NO. 4 383114,318.056-599 FROM IDENT NO. 4 373937 ALSO INSTALLED ON SEE FOOTNNOTE 15
109
FITTING DELIVERY LINE TO PUMP
112
T-FITTING RIGHT SPRING LOAD ACCUMULATOR BRAKE CYLINDER,CONNECTION "1"
113
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
114
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
125
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "22"
135
RESERVOIR ,5 934167, Replaced By: A0034321401
135
RESERVOIR COMPRESSED AIR 20 L
140
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20", Replaced By: N000000006191
143
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
144
O-RING CHECK VALVE TO AIR RESERVOIR
148
NUT CHECK VALVE TO AIR RESERVOIR
151
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
154
O-RING CHECK VALVE TO AIR RESERVOIR
158
T-FITTING (SAFETY VALVE)
162
FITTING , Replaced By: A0019902771
162
ELBOW FITTING DELIVERY LINE TO PUMP
168
T-FITTING , Replaced By: A0019901070
168
T-FITTING INSIDE AND OUTSIDE AIR RESERVOIRS, FRONT CONNECTION
171
NUT CHECK VALVE TO AIR RESERVOIR
174
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
177
O-RING CHECK VALVE TO AIR RESERVOIR
180
FITTING , Replaced By: A0019902771
180
ELBOW FITTING DELIVERY LINE TO PUMP
181
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
182
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
184
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
185
VALVE DRAIN, Replaced By: A0004322407
185
VALVE. DRAIN VALVE DRAIN
185
VALVE DRAIN, Replaced By: A0004322107
189
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
190
O-RING CHECK VALVE TO AIR RESERVOIR
195
CONSOLE , 674067
198
SCREW BRACKET TO FRAME M 12X35
201
CONICAL SPRING WASHER CONSOLE TO FRAME SIDE MEMBER
204
NUT SUPPORT TO SIDE MEMBER
208
STRAP AIR RESERVOIR TO CONSOLE
211
PLATE CONSOLE TO SIDE MEMBER
211
PLATE ,5 317650
214
NUT BRACKET TO SUPPORT AND TO END PIECE
217
BASE AIR RESERVOIR TO CONSOLE
225
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
225
PLASTIC PIPE RISING PIPE 4X6 MM
228
FITTING , Replaced By: N915059004001
228
FITTING LINE CONNECTION TO FIRE WALL,5 726664
231
FITTING
234
INSULATING HOSE BLACK 10 MM, ORDER BY THE METER
237
UNION NUT
240
NUT , Replaced By: N308675012000
240
NUT CAB FLOOR
999
CLAMP , Replaced By: A0059970190
999
CLAMP ,K 147121, Replaced By: N000000000319
999
SLEEVE LINE CONNECTION
999
BANJO UNION FROM PRESSURE REGULATOR TO ANTI-FREEZE DEVICE,6 900001-6 900006
999
BANJO UNION HOSE WIDTH, / I.D., 8/22 MM
999
BANJO UNION HEATING CONNECTION,K 169122
999
BANJO UNION HOSE WIDTH, / I.D., 6/16 MM
999
PLUG ,4 383114 ALSO INSTALLED ON 4 366280,4 366695,4 367047.
999
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
999
UNION NUT LINE CONNECTION
999
NUT , Replaced By: N910113010000
999
NUT , Replaced By: N913004008001
999
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
999
NUT , Replaced By: N913004006001
999
NUT PUMP TO BRACKET
999
NUT STRAP TO BRACKET
999
SCREW BRACKET TO SIDE MEMBER
999
SCREW BRACKET TO CROSS CONNECTION STRUT
999
SCREW PIPE CLAMP
999
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
999
SCREW , Replaced By: N304017006026
999
SCREW PLATE TO VALVE M 6X70
999
SCREW APPARATUS PLATE TO CAB,K 062140
999
SCREW , Replaced By: N000000001146
999
SCREW , Replaced By: N007985006580
999
SCREW , Replaced By: A0029903712
999
SCREW REFLECTOR TO BRACKET
999
SHEET METAL SCREW ,4 383114 ALSO INSTALLED ON 4 366280,4 366695,4 367047.
999
SHEET METAL SCREW BOOT TO CAB FLOOR
999
SEAL RING PNEUMATIC VALVE
999
SEAL RING , Replaced By: N007603010110
999
GLAND LINE CONNECTION
999
NUT INTERMEDIATE SPEED STOP
999
SCREW BRACKET TO SIDE MEMBER
999
SCREW REAR EXHAUST PIPE TO MUFFLER
999
SCREW , Replaced By: N304017010002
999
SCREW END PIECE TO EXHAUST PIPE M 10X25
999
SCREW , Replaced By: N304017008016
999
SCREW , Replaced By: N304017008034
999
SCREW , Replaced By: N304017008021
999
SCREW TEST CONNECTION TO BRACKET
999
SCREW DISTRIBUTOR TO CAB
999
SCREW COVER PLATE TO BRACKET
999
SCREW , Replaced By: N304014006005
999
SCREW CONNECTOR
999
SCREW , Replaced By: N000933006151
999
EXPANSION PLUG ,4 819869
999
WASHER EXHAUST MUFFLER TO STRAP
999
WASHER , Replaced By: N000125008443
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
COTTER PIN CYLINDER TO BRACKET
999
COTTER PIN STRAP TO CONSOLE 20 L
999
HEXALOBULAR BOLT WIRE CABLE TO BRACKET
999
SCREW CLAMP MOUNTING M 6X16
999
BRACKET COMPRESSED AIR LINES
999
BRACKET , Replaced By: A4420981839
999
BRACKET , Replaced By: A4420981239
999
SPACER TUBE
999
TUBE. BUSHING CAB FLOOR COVERING
999
ADHESIVE FOIL GUIDE SIGN
999
BRACKET COMPRESSED AIR LINE TO FOUR-CIRCUIT PROTECTIVE VALVE,5 720506
999
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
999
CLAMP , Replaced By: A3604300143
999
WASHER , Replaced By: A3609902340
999
WASHER BRACKET TO LEFT SIDE MEMBER
999
CLAMP , Replaced By: N916016008200
999
BALL CUP BRAKE INTERMEDIATE SHAFT BEARING
999
REPAIR KIT , Replaced By: A3534200167
999
SPACER TUBE , Replaced By: A4082910153
999
BRACKET , Replaced By: A3812950440
999
LINE FROM TEST CONNECTION TO RIGHT WHEEL CYLINDER 650 MM
999
SEAL RING
999
SEAL HOLDER
999
GUIDE SIGN LOAD-DEPENDING BRAKE
999
GUMMED LABEL INSTRUCTION FOR PARKING BRAKE VALVE
999
BRACKET FLUID RESERVOIR,4 383114 ALSO INSTALLED ON 4 366280,4 366695,4 367047.
999
BRACKET BRAKE BOOSTER,4 282708
999
BRACKET ,4 282708 051,052,053,054,065,066,067,070,072 UP TO CHASSIS 4 383113,056,057,058,059,090,092 UP TO CHASSIS 4 373946 EXCEPT FOR 4 365508, 4 367796,4 368182,4 368578,4 368976,4 369331, Replaced By: A3184313940, +001A3184314040
999
CONSOLE , Replaced By: A3604301311, +001A3604300040
999
BRACKET FLUID RESERVOIR,4 885755
999
BRACKET LEFT,6028918 000001
999
ANGLE , Replaced By: A4220980239
999
BRAKE INTERMEDIATE SHAFT ,4 819869
999
BEARING BRACKET BRAKE INTERMEDIATE SHAFT,4 819869
999
GROMMET ,4 383114 ALSO INSTALLED ON 4 366280,4 366695,4 367047.
999
PROTECTIVE CAP , Replaced By: A0004210887
999
GROMMET BATTERY CASE
999
BRACKET , EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO CHASSIS 4 493018, Replaced By: A3812950440
999
GASKET ,4 383114 ALSO INSTALLED ON 4 366280,4 366695,4 367047.
999
BRACKET , Replaced By: A3184280340
999
BRACKET , Replaced By: A3104280740
999
VALVE CLUTCH SLAVE CYLINDER
999
SPHERICAL PIECE , Replaced By: A3025860242
999
SEAL RING
999
HOSE LEVER TO SUPPORT
999
SEAL RINGTO 001 431 68 06,19.3X2.4 MM,GRAU37001, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
SEAL RING , Replaced By: A0014313060
999
SEAL RING , Replaced By: A0014312960
999
SEAL RING 25.3X2.4 MM,TO 001 431 68 06, 002 431 02 06
999
SEAL RINGTO 000 429 28 95,GRAU
999
SEAL RING22.3X2.4 MM,GRAU
999
HOSE CLAMP LINE MOUNTING
999
FITTING , Replaced By: A0029906171
999
WHEEL BRAKE CYLINDER SLAVE CYLINDER, NOT FOR USE WITH MERCEDES-BENZ CAB
999
WHEEL BRAKE CYLINDER , WITH 8-MM,OR 10-MM,MOUNTING SCREWS, Replaced By: A0074202018
999
VALVE. REPAIR KIT HAND BRAKE LEVER TO 001 430 65 81
999
VALVE (RELAY VALVE) KNORR
999
VALVE (RELAY VALVE) BOSCH
999
FITTING BRAKE HOSE TO COMPRESSED AIR LINE
999
FITTING (PARTS KIT),LINE RUPTURE
999
SCREW , Replaced By: N000000001149
999
EDGE GUARD SECTION SEAT, Replaced By: A0019872272
