Поз.
Артикул
Описание
3
RUBBER MOUNTING ENGINE FRONT SUSPENSION
3
RUBBER MOUNTING ENGINE FRONT SUSPENSION
6
ENGINE STAY RUBBER MOUNTING TO FRONT CROSS MEMBER
9
NUT SUPPORT TO SIDE MEMBER
12
ENGINE CROSS MEMBER REAR
15
RUBBER MOUNTING REAR
15
RUBBER MOUNTING REAR
18
REINFORCEMENT RIGHT
18
REINFORCEMENT LEFT
21
SCREW SUPPORT TO FRAME M12X1,5X35,D 127794
24
NUT ALTERNATOR TO SUPPORT
27
SCREW SUPPORT TO SIDE MEMBER M 12X1.5X35
30
LOCK WASHER FITTING TO BRACKET
33
SCREW CONSOLE TO BRACKET M 12X1.5X25,20 L
36
LOCK WASHER FITTING TO BRACKET
39
SUPPORTING ARM ENGINE RIGHT REAR MOUNTING,D 087894
42
SCREW SUPPORTING ARM TO BELL HOUSING
45
BRACKET OIL LINE ON ENGINE SIDE
48
SCREENING PLATE REAR RUBBER MOUNTING
51
WASHER IN ITS PLACE,YOU MAY ALSO USE MERCEDES-BENZ PART NO.: 360 990 18 40
54
SCREW BRACKET TO SIDE MEMBER M 14X1.5X50,5 543914
57
WASHER CONSOLE TO FRAME
60
SCREW , Replaced By: N308676016004
