Поз.
Артикул
Описание
10
FUEL TANK , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A3834700701, +001A0004710530, +001A0004710235, +001A0085427617, +002A3879900078, +001A0009908188, +001A0119970745, +001A0019975272, +001N007603014302, +001N007604014106, +001N915001006002
10
FUEL TANK105 L,5 218303
15
SEAL RING FUEL STRAINER SCREEN
19
FUEL STRAINER AT TANK
19
FUEL STRAINER FUEL TANK
25
GASKET FUEL GAUGE SENDER UNIT TO FUEL TANK
25
GASKET SENDER UNIT AND COVER TO FUEL TANK
30
SENDER UNIT FUEL GAUGE SENDER UNIT TO FUEL TANK,4 495577
30
SENDER UNIT FUEL GAUGE,5 218303
35
SEAL RING SENDER UNIT AND COVER TO FUEL TANK
39
NUT , Replaced By: N304032005005
39
NUT IN CASE OF SUBSEQUENT INSTALLATION
45
FILLER CAP
45
FILLER CAP , Replaced By: A0004700305
45
FILLER CAP , Replaced By: A0004717930
45
FILLER CAP , Replaced By: A0004700305
45
FILLER CAP
45
FILLER CAP , Replaced By: A0004700305
50
SEAL RING
55
CHAIN FILLER CAP
65
SUPPORT FUEL TANK
70
SCREW , Replaced By: N308676012026
70
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
74
LOCK WASHER FITTING TO BRACKET
78
WASHER , Replaced By: N007349013005
78
WASHER MOUNTING USED FOR FRAME CONNECTION PARTS
85
STRAP FUEL TANK TO SUPPORT, UP TO IDENT NO. 734559 EXCEPT FOR 500001-599999
90
PAD FUEL TANK TO SUPPORT, ORDER BY THE METER
95
PAD FUEL TANK TO SUPPORT, ORDER BY THE METER
100
WASHER STRAP TO SUPPORT
104
NUT STRAP TO SUPPORT
110
HOSE FEED & RETURN 8X11MM, ORDER BY THE METER
114
HOSE FROM WARNING INDICATOR TO AIR CLEANER, ORDER BY THE METER
118
BANJO UNION , Replaced By: N915052008001
118
BANJO UNION FROM PRESSURE REGULATOR TO ANTI-FREEZE DEVICE,6 900001-6 900006
122
BANJO UNION , Replaced By: N915052008019
122
BANJO UNION FROM PRESSURE REGULATOR TO ANTI-FREEZE DEVICE,6 900001-6 900006
126
BANJO UNION , Replaced By: N000000000363
130
BANJO UNION , Replaced By: N915052004019
130
BANJO UNION HOSE WIDTH, / I.D., 4/16 MM
136
BUSHING , Replaced By: N915062004000
136
SLEEVE LEAK LINE
140
HOSE LEAK LINE, ORDER BY THE METER
145
LOOM TIE LINE MOUNTING
150
SEAL RING CONNECTION: 1,4 719029
154
SEAL RING
154
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
157
HOSE FEED & RETURN 8X11MM, ORDER BY THE METER
160
HOLLOW SCREW RISING PIPE, ON MOTOR 352-358 UP TO IDENT NO. 4 292267,ON MOTOR 360 UP TO IDENT NO. 4 675310 008 997 54 82,446 MM LONG
164
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
170
BRACKET COMPRESSED AIR LINE TO SIDE MEMBER
170
BRACKET , Replaced By: A3184280240
170
BRACKET LINE MOUNTING
175
BRACKET LINE MOUNTING
180
SCREW , Replaced By: N304017008021
180
SCREW PIPE CLAMP
184
NUT , Replaced By: N913004008001
184
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
190
SEAL RING FUEL LINE TO FEED PUMP
190
SEAL RINGTO 000 553 03 05,000 553 18 05,
195
HOLLOW SCREW , Replaced By: N915036010108
195
HOLLOW SCREW FUEL LINE TO FEED PUMP
200
HOLLOW SCREW TWO-WAY VALVE,CONNECTIONS: "11,12"
999
UNION NUT
999
CLAMP LEAK LINE TO CONNECTOR AT ENGINE
999
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
999
HOSE HAND BRAKE VALVE BLEEDING 100 MM, ORDER BY THE METER
999
SCREW PLUG FUEL TANK
999
SCREW PLUG , Replaced By: N007604014110
999
SCREW , Replaced By: N304017008027
999
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
999
FUEL STRAINER FUEL GAUGE SENDER UNIT TO FUEL TANK
999
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
999
LOOM TIE LINE MOUNTING 280 MM
999
FITTING RETURN LINE
999
BANJO UNION FEED LINE
