Поз.
Артикул
Описание
6
7
7
8
8
10
11
UNION NUT
11
UNION NUT LINE MOUNTING
13
GLAND , Replaced By: A0019901167
13
GLAND , Replaced By: A0019901667
15
FITTING AIR RESERVOIR,CONNECTION: "15",5 433280
15
FITTING LINE CONNECTION
16
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
16
THRUST RING CHECK VALVE TO AIR RESERVOIR
17
O-RING CHECK VALVE TO AIR RESERVOIR
18
19
20
BRACKET , Replaced By: A3864297040
21
MUFFLER FROM AIR COMPRESSOR TO PRESSURE REGULATOR,095094 UP TO IDENT NO.099977, INOLTRE MONTATO IN 099368,099369
22
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBER M10X25
23
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
35
BRAKE HOSE COMPRESSED AIR HOSE
36
CONNECTION FITTING , Replaced By: N003902018002
37
CONNECTOR SOLENOID VALVE,CONNECTION: "2" TOA388 997 81 36 / 88 36
37
CONNECTOR AT AIR COMPRESSOR, USED WITH HYDRAULIC BRAKE,UP TO CHASSIS 588185
38
SEAL RING ENGINE AIR COMPRESSOR,CONNECTION: "20"
38
SEAL RING LINE CONNECTION
39
PLASTIC PIPE12X16 MM, ORDER BY THE METER
39
PLASTIC PIPE FUEL LINE 16X2 MM, ORDER BY THE METER
40
FITTING (PARTS KIT),LINE RUPTURE
999
PLUGM12X1.5
999
CONNECTOR PRESSURE REGULATOR BREATHING
999
T-FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 22
999
T-FITTING HOSE WIDTH, 6 MM
999
T-FITTING
999
ELBOW FITTING HOSE WIDTH, 9 MM,TO M 16
999
T-FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M22 / 9MM / 9MM / VOSS 230,D 248571
999
THROTTLE HOUSING. FITTING
999
ELBOW FITTING12 MM / M22X1,5 / VOSS 230
999
999
999
CLAMP LINE MOUNTING
999
SCREW BRACKET AND CLAMP M6X20
999
HEXAGON HEAD BOLT BRACKET TO BRACKET M8X25
999
NUT BRACKET TO FIRE WALL
999
NUT HORN TO BRACKET M8
