Поз.
Артикул
Описание
354
LINE FROM HYDRAULIC LINE TO CONNECTION FITTING 2000 MM, NOT USED
354
LINE , Replaced By: A3812902214
361
CLAMP LINE MOUNTING
368
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
375
NUT PUMP TO BRACKET
375
NUT , Replaced By: N913004006001
382
INTERMEDIATE PIECE CLUTCH HOSE,K 172342
389
LINE , Replaced By: A3812902414
389
LINE FROM FITTING TO CLUTCH BOOSTER 3000 MM
396
INTERMEDIATE PIECE CLUTCH HOSE,K 172342
403
BRACKET COMPRESSED AIR LINE TO FOUR-CIRCUIT PROTECTIVE VALVE,5 720506
410
SCREW , Replaced By: N304017006020
410
SCREW LICENSE PLATE TO BRACKET
417
NUT , Replaced By: N913004006001
417
NUT PUMP TO BRACKET
424
CLAMP LINE MOUNTING
431
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
438
WASHER COMPRESSED AIR LINE TO BRACKET
438
WASHER , Replaced By: N009021006208
445
NUT , Replaced By: N913004006001
445
NUT PUMP TO BRACKET
452
HOSE FROM REAR ENGINE-MOUNTING BRACKET TO TRANSMISSION BRACKET 350 MM
459
BRACKET AT SIDE MEMBER,5 157363
466
SCREW LICENSE PLATE TO BRACKET
466
SCREW BRACKET TO CROSS CONNECTION STRUT
466
SCREW PIPE CLAMP
466
SCREW , Replaced By: N304017006020
466
SCREW , Replaced By: N304017008021
466
SCREW , Replaced By: N304017008034
473
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
473
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
480
NUT , Replaced By: N913004008001
487
MOUNTING PLATE FROM EXPANSION TANK TO RADIATOR
487
BRACKET. LOCK , Replaced By: A6525040038
494
BRACKET HYDRAULIC LINE,950198
501
SCREW BRACKET TO CROSS CONNECTION STRUT
501
SCREW , Replaced By: N304017008034
508
NUT , Replaced By: N913004008001
515
LINE FROM CLUTCH MASTER CYLINDER TO SHUTTLE VALVE 400 MM, TO BE ADAPTED DURING ASSEMBLY
515
LINE , Replaced By: A3812901514
522
SLAVE CYLINDER CLUTCH
529
BOOT
536
ROD
543
VALVE CLUTCH SLAVE CYLINDER
550
PROTECTIVE CAP , Replaced By: A0004217187
550
PROTECTIVE CAP ,5 962906
557
CIRCLIP POWER CYLINDER TO THROTTLE VALVE LEVER
564
REPAIR KIT , Replaced By: A0002900811
564
REPAIR KIT CLUTCH SLAVE CYLINDER
571
SCREW SUPPORT TO CROSS MEMBER M 10X28
578
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
999
PROTECTIVE PLATE , Replaced By: A3522510106
999
PROTECTIVE PLATE BELL HOUSING,5 332727 SEAL DURING ASSEMBLY
