Поз.
Артикул
Описание
313
FRAME BATTERY CARRIAGE
317
NUT POWER CYLINDER TO BRACKET
317
NUT , Replaced By: A0009903250
321
GUIDE RAIL RIGHT
321
GUIDE RAIL LEFT
325
ANGLE CENTRAL AND REAR
329
ANGLE FRONT RIGHT
329
ANGLE FRONT LEFT
333
SCREW GUIDE TO STEERING COLUMN END,5 227753
337
NUT TWO-WAY VALVE TO BRACKET
341
STOP BATTERY CARRIAGE
345
SCREW PUMP TO BRACKET
345
SCREW , Replaced By: N304017006016
349
NUT PUMP TO BRACKET
349
NUT , Replaced By: N913004006001
353
FASTENER BATTERY CASE
357
SCREW LOCK TO BATTERY CARRIAGE
357
SCREW DIODE CASE TO OPERATING UNIT CASE
361
NUT TWO-WAY VALVE TO BRACKET
365
BOW BATTERY CASE LOCK
369
SCREW LICENSE PLATE TO BRACKET
369
SCREW , Replaced By: N304017006020
373
NUT PUMP TO BRACKET
373
NUT , Replaced By: N913004006001
377
CHAIN TO SECURE BATTERY CASE
381
HOOK BATTERY MOUNTING
385
REST BATTERY TO BATTERY CARRIAGE
385
REST , NOT USED
389
NUTTO 000 466 38 02
999
DIAGRAM PAPER SET100 PIECES
999
CONNECTION PLATE
999
BOOT PIN BUSHING
999
PIN BUSHING HOUSING PIN BUSHING 5.3 MM
999
GROMMET LINE MOUNTING 10.0 MM
999
BULB24 V
999
SWITCH EXHAUST BRAKE
999
PLUG FROM CHASSIS/CAB CONNECTION POINT TO TACHOGRAPH 2.5 MM2
999
PIN BUSHING HOUSING UNIPOLAR
999
PIN BUSHING HOUSING UNIPOLAR
999
PLUG LESS DETENT,BUT WITH CATCH FOR HOUSING 4-6 MM2
999
CONTROL UNIT OVERLOAD PROTECTOR
999
PLUG HOUSING 8-POLE
999
PIN BUSHING HOUSING 6-POLE
999
PIN BUSHING HOUSING 3-POLE
999
PLUG HOUSING 5-POLE
999
PIN BUSHING ELECTRIC CABLE CONNECTION
999
PIN BUSHING HOUSING 4-POLE
999
PLUG HOUSING 6-POLE
999
BRACKET BRACKET TO SIDE MEMBER, TO BE ADAPTED DURING ASSEMBLY
999
PIN BUSHING HOUSING 8-POLE
999
BOOT NEG. CABLE
999
BOOT STEERING COLUMN MOUNTED SWITCH, NO.8316 INO.7C52 IIIII I
999
BRACKET , Replaced By: A3634292740
999
999
999
SUPPORT RESERVOIR AND LINES, UP TO IDENT NO. 950253,FROM IDENT NO.SEE GROUP 54
999
999
999
999
CABLE CONNECTOR JUNCTION BOX
999
SPRING TO SECURE BATTERY CASE
999
SCREW , Replaced By: N304017005011
999
SCREW CAB FLOOR COVERING M 6X25
999
SCREW COVER PLATE TO BRACKET
999
SCREW , Replaced By: N304017008021
999
WASHER , Replaced By: N009021006208
999
WASHER COMPRESSED AIR LINE TO BRACKET
999
SCREW COVER PLATE TO BRACKET
999
SCREW PIPE CLAMP
999
NUT , Replaced By: N913004008001
999
ELECTRIC CABLE FROM BATTERY TO BATTERY SUPPORT, ORDER BY THE METER
