Поз.
Артикул
Описание
4
BEARING BRACKET , 000202
8
PEDAL
11
BUSHING BRAKE PEDAL
11
BUSHING , Replaced By: A1242920050
14
BUSHING
17
PAD BRAKE PEDAL
20
COVER PLATE
23
BUSHING
25
SCREW BRACKET TO FRAME
27
WASHER
29
NUT END PIECE TO EXHAUST PIPE
31
BRACKET
33
SCREW LEVER TO SHAFT
33
SCREW , Replaced By: N304017005002
36
LOCK WASHER BRACKET TO STEERING COLUMN END
38
BRACKET , FROM CHASSIS 001029 ALSO INSTALLED ON, SEE FOOTNOTE 3
44
SCREW VALVE TO BRACKET M 8X55
44
SCREW , Replaced By: N304017008043
47
WASHER , Replaced By: N000125008443
47
WASHER EXHAUST MUFFLER TO STRAP
50
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
52
SCREWM 8X60
52
SCREW , Replaced By: N007984008041
54
SPRING WASHER , Replaced By: N000137008212
54
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
999
BRACKET , 000985
999
BRACKET , FROM CHASSIS 000986-001028 EXCEPT FOR, SEE FOOTNOTE 3
999
BEARING BRACKET , 000201
999
BEARING BRACKET , 000201
999
BEARING BRACKET , 000202
999
SCREW , Replaced By: N304017005002
999
WASHER , Replaced By: N009021005205
999
WASHER CABLE CONNECTOR TO BRACKET AND TO FRAME,RESP.
