Поз.
Артикул
Описание
5
AIR CELL LEFT
7
SEAL RING
10
AIR SPRING BELLOWS
13
RING
15
SCREW
18
LOCK WASHER PARKING BRAKE VALVE TO WINDOW SILL,013035
21
NUT
24
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
28
PISTON
30
SCREW BRACKET TO INTAKE MANIFOLD
30
SCREW , Replaced By: N007984008003
33
LOCK WASHER PARKING BRAKE VALVE TO WINDOW SILL,013035
82
TORSION BAR
85
RUBBER MOUNTING , 000523
88
SCREENING PLATE
91
BRACKET , 000523
93
SCREW SUPPORT TO CYLINDER CRANKCASE
95
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
97
SCREW
99
RETAINER
103
RUBBER BUFFER
106
SPACER TUBE
108
NUT AIR CLEANER ELEMENT
173
SHOCK ABSORBER FRONT
176
RUBBER MOUNTING
178
RUBBER BUFFER
181
RETAINER FRONT SHOCK ABSORBERS TO FRAME
181
RETAINER , Replaced By: A1233230367
183
SPACER TUBE SHOCK ABSORBER TO FRAME
185
RUBBER MOUNTING
188
REPAIR KIT
191
DUST CAP
193
NUT , Replaced By: N308673010000
193
NUT SHIFT LEVER HANDLE TO SHIFT LEVER
196
SCREW , Replaced By: N304017008034
198
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
201
BOOT
235
ANTI-FREEZE DEVICE
237
RESERVOIR
247
SCREW PLUG
250
SEAL RING101
250
SEAL RING , Replaced By: A0179974148
252
SEAL RING
254
NOZZLE SIZE 100
257
FILTER
259
SEAL RING
264
FITTING AIR CLEANER TO BODY
266
CLAMP , 000015
272
RESERVOIR
274
GROMMET FOR PASSAGE OF LINE
276
VALVE PRESSURE REGULATOR
278
SCREW PLUG
280
SEAL RING
283
VALVE
286
RETAINER
288
RUBBER MOUNTING AIR RESERVOIR TO CROSS MEMBER AND TO WHEELHOUSE STRUT
291
SPACER TUBE AIR RESERVOIR TO CROSS MEMBER AND TO WHEELHOUSE STRUT
293
SCREW BRACKET TO FIRE WALL
296
LOCK WASHER
299
SCOOP , 000301
302
THREADED UNION , 000301
306
SEAL RING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "1,2"
308
LOCK RING , Replaced By: N900055020303
345
VALVE FRONT LEFT
347
VALVE FRONT RIGHT
349
FITTING
351
SEAL RING
353
SEAL RING
355
SCREW VALVE TO BRACKET
357
SPRING WASHER , Replaced By: N000137008212
360
ROD
362
NUT BALL PIVOT TO LEVER
364
JOINT , Replaced By: A1233280063
364
JOINT R.H. THREAD
367
NUT L.H. THREAD
369
JOINT , Replaced By: A1233280163
369
JOINT L.H. THREAD
371
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
373
NUT BATTERY MOUNTING
373
NUT CYLINDER TO BRACKET TO0002902112
999
LOCK FROM CONNECTING HOSE TO SLAVE CYLINDER, 000,001,004,010,016 FROM CHASSIS 064106 ALSO INSTALLED ON, SEE FOOTNOTE 5, 100,101,104,110,116 FROM CHASSIS 099642 ALSO INSTAL LED ON, SEE FOOTNOTE 6, EXCEPT FOR 099892
999
PIN , FROM CHASSIS 020071
999
VALVE , 000962, Replaced By: A0003274625, +001A1003200591
999
VALVE , UP TO CHASSIS 020070, Replaced By: A0003274725, +001A0003270074
999
VALVE DISC
999
SPRING RETAINER
999
SPRING
999
HOSE , ORDER BY THE METER 107.022 005201 ALSO INSTALLED ON 005190-005192,005194-005199. 107.023 012497 107.024 021804 ALSO INSTALLED ON 021794,021804
999
HOSE ORDER BY THE METER, UP TO CHASSIS: 000,002,010 10/50 062913, ALSO INSTALLED ON: 063054,063061,063065 12/52 062722 20/60,22/62 062286 057536, SWEDEN UP TO CHASSIS: 015 10/50 069223, EXCEPT FOR: 069202 12/52 068866 20/60,22/62 068662 062825, SWEDEN
999
WIRE CABLE , 000963
999
AIR CELL RIGHT
999
LINE , Replaced By: A1093208853
999
LINE , Replaced By: A1093208953
999
LINE , FROM CHASSIS 000966 ALSO INSTALLED ON 000942,000944,000947,000948,000951,000952,000964
999
SPACER TUBE ,002383, Replaced By: A1003230653, +001A1153230767
999
RUBBER MOUNTING , 000522, Replaced By: A1003231485, +001A1003231840
999
BRACKET , 000522, Replaced By: A1003231840, +001A1003231485
999
FITTING , 000015, Replaced By: A1003270565, +001A1009950101
999
LINE FROM CONNECTOR TO CONTROL VALVE
999
CLAMP AIR CLEANER TO BODY
999
HOSE , 000581
999
LINE , Replaced By: A1093208953
999
LINE , 016 FROM CHASSIS 001859 ALSO INSTALLED ON, SEE FOOTNOTE 3, 018 FROM CHASSIS 002020 ALSO INSTALLED ON 001907, 001911 TO BE ADAPTED DURING ASSEMBLY
999
KNOB , UP TO CHASSIS: 000,002,010 10/50 062913, ALSO INSTALLED ON: 063054,063061,063065 12/52 062722 20/60,22/62 062286 057536, SWEDEN UP TO CHASSIS: 015 10/50 069223, EXCEPT FOR: 069202 12/52 068866 20/60,22/62 068662 062825, SWEDEN
999
GUIDE , UP TO CHASSIS: 000,002,010 10/50 062913, ALSO INSTALLED ON: 063054,063061,063065 12/52 062722 20/60,22/62 062286 057536, SWEDEN UP TO CHASSIS: 015 10/50 069223, EXCEPT FOR: 069202 12/52 068866 20/60,22/62 068662 062825, SWEDEN
999
DAMPING STRIP BRAKE LINE TO SIDE MEMBER
999
SCREW
999
HOUSING , Replaced By: A1233230367
999
CLAMP FORKED SUPPORT,TOP
999
CLAMP TO MOUNT MAIN CABLE HARNESS
999
SCREW , Replaced By: N304017006018
999
SCREW COVER PLATE TO BRACKET
999
NUT AIR INTAKE PIPE TO AIR INTAKE PIPE,937184
999
NUT CYLINDER TO BRACKET TO0002902112
999
SHEET METAL SCREW BRACKET TO CAB 4,2X13
999
SCREW STEERING COLUMN MOUNTED SWITCH TO STEERING COLUMN BRACKET M4X10
999
SCREW , Replaced By: N007985004107
999
WASHER , Replaced By: N009021005205
999
WASHER CABLE CONNECTOR TO BRACKET AND TO FRAME,RESP.
999
CLAMP WATER TEMPERATURE GAUGE CABLE TO FIRE WALL
999
SCREW COVER PLATE TO COVER PLATE M 6 X 12
999
CLAMP
999
LOCK WASHER WIPER PULSE SENDER UNIT
