Главная
›
Mercedes
›
TRANSMISSION
›
S 6-90 WSK 400+N 90/10
›
719.520
›
26 TRANSMISSION
›
700 P.T.O. DEPENDENT ON TRANSMISSION IL. 1
Mercedes N000125008443 - ШАЙБА
S 6-90 WSK 400+N 90/10 719.520
26 TRANSMISSION - 700 P.T.O. DEPENDENT ON TRANSMISSION IL. 1
Поз.
Артикул
Описание
98
A0002606663
SHIFTING CYLINDER PNEUMATIC SHIFTING CYLINDER
98
A0002603263
SHIFTING CYLINDER , Replaced By: A0002606663
101
A0002640260
SEAL RING
104
A0002640193
SPRING
107
A0002640093
SPRING
110
A0002640086
STOP RING
113
N007993048200
SNAP RING SHIFTING CYLINDER
116
A0002640696
BOOT
116
A0002640096
BOOT , Replaced By: A0002640696
119
N304035010001
NUT
119
N913021010001
NUT , Replaced By: N304035010001
122
A3619960201
YOKE , Replaced By: A0009962801
122
A0009962801
YOKE
125
N918001008002
PINM 8 X 16
128
A0002640076
WASHER
131
A0002640092
STRAINER
134
N001434008020
PIN PULL ROD TO SHIFT LEVER
137
N000125008418
WASHER , Replaced By: N000125008443
137
N000125008443
WASHER EXHAUST MUFFLER TO STRAP
140
N000094002060
COTTER PIN LEVER TO ROD
140
N000094002059
COTTER PIN LEVER TO ROD, Replaced By: N000094002060
143
N007603010116
SEAL RING OIL DISTRIBUTOR BLOCK
146
N000910010000
SCREW PLUG
149
A0002603068
REPAIR KIT PNEUMATIC SHIFTING CYLINDER TO 000 260 66 63
