Поз.
Артикул
Описание
8
WHEELHOUSE FRONT LEFT WITH SIDE MEMBERS
15
BRACKET BRAKE HOSE, LEFT FRONT
28
STRUT FRONT LEFT
36
RETAINER
47
PLATE
53
CONSOLE FRONT AXLE LEFT BRACING
73
SUPPORT FRONT
79
CONSOLE FRONT LEFT SHOCK ABSORBER
90
CROSS MEMBER FRONT, 024/025 FROM CHASSIS 003545 ALSO INSTALLED ON 003479,003498,003515-003519,003521,003522,003524-003530,003532-003534,003536-003 543
105
BAFFLE , Replaced By: A1116205572
105
STIFFENING FRONT, 024/025 FROM CHASSIS 003545 ALSO INSTALLED ON 003479,003498,003515-003519,003521,003522,003524-003530,003532-003534,003536-003 543
111
EYE FRONT
122
ANGLE LEFT (ENGINE SHOCK ABSORBER)
128
REST
147
EXPANSION PLUG ELECTRIC CABLE THRU FIRE WALL,4 9400475 187082
147
EXPANSION PLUG , Replaced By: A1139870044
154
INSTRUMENT PANEL SHELL
159
PANELLING
163
TUBE
175
TRUNNION BEARING
188
ADHESIVE TAPE (SEAL),BETWEEN OUTSIDE REAR PILLAR AND ROOF 560 MM, ORDER BY THE METER
198
SHELL
203
GROMMET
208
CLAMP
214
SHEET METAL NUT CONDENSER TO FRONT STIFFENING
218
BRACKET LIQUID TANK
224
CONNECTION
231
MOUNTING CONTROL LINKAGE TO FIRE WALL, CENTER
999
SHEET METAL NUT , Replaced By: N913008006300
999
RUBBER SECTION , Replaced By: A0009876233
999
STRUT BETWEEN STIFFENING AND FRONT CROSS MEMBER
999
BRACKET FUEL FINE-MESH FILTER, 003778
999
CONSOLE FRONT RIGHT SHOCK ABSORBER
999
CONSOLE FRONT AXLE RIGHT BRACING
999
BAFFLE , Replaced By: A1116205572
999
BRACKET KICK-DOWN, NO LONGER AVAILABLE
999
STRUT FRONT RIGHT
999
COWL , Replaced By: A1116206505
999
COWL LESS FIRE WALL, NO LONGER AVAILABLE, ORDER INDIVIDUAL PARTS
999
REST
999
STRUT FRONT RIGHT
999
COWL , Replaced By: A1116206505
999
COWL LESS FIRE WALL, NO LONGER AVAILABLE, ORDER INDIVIDUAL PARTS
999
INSTRUMENT PANEL SHELL
999
COWL LESS FIRE WALL, NO LONGER AVAILABLE, ORDER INDIVIDUAL PARTS
999
COWL LESS FIRE WALL
999
COWL LESS FIRE WALL, NO LONGER AVAILABLE, ORDER INDIVIDUAL PARTS
999
COWL LESS FIRE WALL, NO LONGER AVAILABLE, ORDER INDIVIDUAL PARTS
999
COWL LESS FIRE WALL, NO LONGER AVAILABLE, ORDER INDIVIDUAL PARTS
999
WHEELHOUSE FRONT RIGHT WITH SIDE MEMBERS
999
WHEELHOUSE FRONT LEFT WITH SIDE MEMBERS
999
FRONT PANEL , FROM CHASSIS 002864 ALSO INSTALLED ON 002123,002193,002327,002402,002539,002546,002726,002731,002744,002748,002757,002760,0027 63,002797,002862
999
FRONT PANEL LESS INSTRUMENT PANEL
999
WHEELHOUSE FRONT RIGHT WITH SIDE MEMBERS
999
FRONT PANEL LESS INSTRUMENT PANEL, FROM CHASSIS 002864 ALSO INSTALLED ON 002123,002193,002307,002402,002539,002546,002726,002731,002744,002748,002757,002760,0027 63,002797,002862
999
WHEELHOUSE , Replaced By: A1116209261
999
WHEELHOUSE FRONT RIGHT LESS SIDE MEMBERS
999
WHEELHOUSE FRONT LEFT LESS SIDE MEMBERS
999
WHEELHOUSE FRONT RIGHT LESS SIDE MEMBERS
999
REINFORCEMENT
999
BRACKET BRAKE HOSE, LEFT FRONT
999
CONNECTION AT WHEELHOUSE PANEL AND AT FIRE WALL, RIGHT
999
BRACKET LIQUID TANK
999
SHEET METAL NUT , Replaced By: N913008006300
999
WASHER BRACKET TO CAB REAR PANEL
999
WASHER , UP TO CHASSIS: 017 029988 114 000523 117 064694
999
SCREW COVER PLATE TO BRACKET
999
SCREW , Replaced By: N304017008016
999
SHEET METAL SCREW BRACKET TO WINDOW SILL
999
SCREW
999
WASHER , Replaced By: N009021006208
999
WASHER COMPRESSED AIR LINE TO BRACKET
999
WASHER , Replaced By: N009021008213
999
WASHER BRACKET TO LEFT SIDE MEMBER
999
SCREW PUMP TO BRACKET
999
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
