Поз.
Артикул
Описание
10
REAR LID
12
HINGE LEFT
15
PIN
17
BASE PLATE
19
SCREW BRACKET TO AIR INTAKE PIPE
21
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
23
WASHER COMPRESSED AIR LINE TO BRACKET
23
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
25
SPRING
27
FLAP
30
LOCK GROMMET TO CAB,4 940046
36
SPRING
38
RUBBER BUFFER
43
INTERMEDIATE LAYER6 MM, FROM CHASSIS: 010 054508 110 134760 017,114,117 000001
46
SEAL
49
RUBBER BUFFER
51
HANDLE
55
PAD
65
LOCK
67
BUFFER , Replaced By: A1169870539
67
RUBBER BUFFER , UP TO CHASSIS: 011 103290 015,017 215059 060 105269 062 103388
69
BASE PLATE
71
PLATE , Replaced By: A1167500011
73
SCREW
76
NUT RETAINER ,123 415950
78
LOCK LESS KEY, STATE LOCK NUMBER WHEN ORDERING
80
LINING
82
PAD
84
NUT TWO-WAY VALVE TO BRACKET
86
FILLER
90
MERCEDES STAR
92
RUBBER RING
999
NUT
999
SCREW BATTERY CABLE MOUNTING AND MAIN CABLE HARNESS MOUNTING
999
SCREW , Replaced By: N007985005157
999
SHEET METAL SCREW BRACKET TO FLOOR PLATE, Replaced By: N000000000460
999
SHEET METAL SCREW BRACKET TO CAB 4,2X13
999
NUT , Replaced By: N304032008006
999
SPRING WASHER ALTERNATOR CONNECTION D+
999
WASHER , Replaced By: N000125008443
999
SHEET METAL SCREW BRACKET TO FLOOR PLATE
999
SPRING , EXHAUST STOCK OF OLD PARTS UP TO CHASSIS 015 249261 017 036714 110 438990 114 004885 115 263609 117,119 073788, Replaced By: A1237580336
999
HINGE RIGHT
999
LOCK WORKSHOP VERSION, WITH KEY, USED WITHOUT CODE 466 (CENTRAL LOCKG.MECHANISM)
999
REAR LID , UP TO CHASSIS: 015 200000 110 400000 115 200000, Replaced By: A1157500675, +001A1077580202, +001A1077580205, +001A2018200801, +004N000137004101, +004N007985004149
999
FLAP , Replaced By: A1157500106
999
LOCK
999
NUT , Replaced By: N913004005001
