Поз.
Артикул
Описание
5
STARTING MOTOR12 V, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
6
EXCITER COIL , TO 002 151 71 01
7
SCREW , TO 002 151 71 01
9
BUSHING INTERMEDIATE BEARING TO 002 151 64 01,002 151 69 01, 940 10/50,20/60 211713 940 12/52,22/62 008163
10
PINIONTO 002 151 71 01
14
BUSHING
16
SOLENOID SWITCHTO 002 151 31 01/002 151 71 01
16
SOLENOID SWITCH , Replaced By: A0011521110
21
CARBON BRUSH SET , Replaced By: A0001517014
21
CARBON BRUSH SET LESS CABLE,TO BE SOLDERED IN 4
27
SPRINGTO 002 151 71 01
33
BUSHING DRIVE END BEARING TO 003 151 07 01,001 151 64 01
38
BEARING BUSHING. BUSHINGTO 002 151 15 01/002 151 31 01
40
GASKET KITTO 002 151 71 01
43
BRACKET
47
SPRING WASHER LICENSE PLATE TO BRACKET
51
NUT BATTERY MOUNTING
51
NUT CYLINDER TO BRACKET TO0002902112
56
SCREW BRACKET TO FRAME
62
SCREW BRACKET TO TRANSMISSION CASE
69
SPRING WASHER CAB FLOOR
72
NUT STRAP TO SUPPORT,5 149419
77
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
77
SCREW , Replaced By: N304017008016
82
WASHER , Replaced By: N000125008443
82
WASHER EXHAUST MUFFLER TO STRAP
88
BRACKET
92
WASHER CONSOLE TO CAB
97
ALTERNATORBOSCH, 55 A, 931 10/50,20/60 002073 931 12/52,22/62 000003 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
97
ALTERNATOR , EXHAUST STOCK OF OLD PARTS UP TO ENGINE: 616.910 10/50,20/60 041194 616.910 12/52,22/62 000368 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART, Replaced By: A0051547402
97
ALTERNATOR , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART, Replaced By: A0071544502
99
GROOVED BALL BEARING , Replaced By: N000625436303
99
GROOVED BALL BEARING
101
RECTIFIER
101
RECTIFIER , Replaced By: A0001548216
101
RECTIFIERTO 007 154 33 02/ 52 02/ 60 02
114
REGULATOR AND CUT-OUT , Replaced By: A0021541806
114
REGULATOR AND CUT-OUT , Replaced By: A0021547206
114
REGULATOR AND CUT-OUT (ELECTRONIC FIELD REGULATOR) TO 005 154 32 02
114
REGULATOR AND CUT-OUTTO 007 154 60 02, 008 154 26 02
119
SPRING
121
CARBON BRUSH SETTO 009 154 07 02
121
CARBON BRUSH SET , Replaced By: A0001548114
121
CARBON BRUSH SETTO 005 154 34 02
129
WOODRUFF KEY
134
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
138
NUT , Replaced By: N308675014000
138
NUT , Replaced By: N308675014002
138
NUT RELEASE BEARING LUBRICATION
140
GROOVED BALL BEARING
140
GROOVED BALL BEARING SLIP RING SIDE
144
REPAIR KIT , Replaced By: A0001500372
144
REPAIR KIT ROTOR TO 005 154 52 02
151
PULLEY , Replaced By: A0001557115
151
PULLEY
151
PULLEY
152
FANTO 007 154 60 02
152
FAN , Replaced By: A0001556318
182
SUPPORT , FROM ENGINE 923 10/50,20/60 142463 923 12/52,22/62 026810 926 10/50,20/60 007797 926 12/52,22/62 000298
187
BUSHING , FROM ENGINE 923 10/50,20/60 142463 923 12/52,22/62 026810 926 10/50,20/60 007797 926 12/52,22/62 000298
198
NUT
198
NUT , Replaced By: N304032010002
202
GROUND CABLE , 938 10/50,20/60 048052 938 12/52,22/62 012310 939 10/50,20/60 006356 939 12/52,22/62 000346 954 10/50,20/60 056714 954 12/52,22/62 030275 955 002760 972 003195
202
GROUND CABLE FROM ALTERNATOR TO GROUND
204
COMBINATION BOLT CONTROL UNIT TO BRACKET
207
SCREW ALTERNATOR TO SUPPORT
212
NUT
212
NUT , Replaced By: N304032010002
226
CLAMPING BOLT ALTERNATOR READJUSTMENT
231
WASHER , Replaced By: N000125010532
231
WASHER RADIATOR TO RUBBER MOUNTING
236
NUT
236
NUT , Replaced By: N304032010002
243
SPACER TUBE GROUND CABLE TO ALTERNATOR
249
BRACKET ALTERNATOR READJUSTMENT
253
SCREW FROM COUPLING PIECE TO DISTRIBUTOR AT CROSS MEMBER, NOT USED
253
SCREW , Replaced By: N304014010005
257
NUT , Replaced By: N304032010002
257
NUT
999
CARBON BRUSH SET , Replaced By: A0001516614
999
RECTIFIERTO 006 154 89 02, 007 154 61 02
999
PULLEY
999
SUPPRESSOR PLUG , Replaced By: A0001564510
999
SUPPRESSOR PLUG , Replaced By: A0001565210
999
SUPPRESSOR PLUG , ONLY REPLACEABLE BY THE SET THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0001564910
999
SUPPRESSOR PLUG , Replaced By: A0001564510
999
SUPPRESSOR PLUG SPARK PLUG
999
SUPPRESSOR PLUG , ONLY REPLACEABLE BY THE SET, Replaced By: A0001564910
999
PIPE LINE , Replaced By: A0001581435
999
PIPE LINE , Replaced By: A0001581435
999
POINT UNIT , Replaced By: A0001584090
999
IGNITION CABLE CYLINDERS NOS.3,4 500 MM, 938 10/50,20/60 038910 938 12/52,22/62 010501 954 10/50,20/60 046750 954 12/52,22/62 024701 939 10/50,20/60 004620 939 12/52,22/62 000274 ORDER BY THE METER
999
CABLE SLEEVE IGNITION DISTRIBUTOR, UP TO IDENT NO. 240087 + FROM IDENT NO. 500001-556499 EXCEPT FOR 236260,237247,237248,239123
999
REGULATOR AND CUT-OUT , Replaced By: A0021545106
999
ALTERNATOR , LESS INDIVIDUAL PARTS PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART, Replaced By: A0041541802
999
HOSE , Replaced By: A1179970982
999
BRACKET , Replaced By: A1101590540
999
HOSE , Replaced By: A1170780281
999
HELICAL GEAR
999
IGNITION CABLE , Replaced By: A0001594118
