Mercedes A0009972040 - КОЛЬЦО УПЛОТНИТЕЛЬНОЕ

TYP 180a BM 120.010, .011 120.010

30 CONTROL - 015 CONTROL

Поз.
Артикул
Описание
1
A1213011001
ACCELERATOR PEDAL
2
A1213010082
COVERING WITH INSERT
3
A1213010018
BEARING
6
A1839970081
GROMMET
7
A6213000020
CONTROL SHAFT
8
A1213020014
LEVER FOR RELEASE SPRING
9
A1809931710
SPRING
10
A1809900017
SCREW LEVER TO SHAFT, 014 UP TO CHASSIS 039989,021/023 UP TO CHASSIS 039959
13
A1213010215
ROD
14
A1803010097
BOOT
17
A1803001830
CHOKE CABLE WITHOUT KNOB. WIRE CABLE , Replaced By: A3093000730
19
A0009880172
WIRE SPIRAL860 MM, WITH GASOLINE ENGINE ORDER BY THE METER
21
A0009972040
SEAL RING CHOKE CABLE TO INSTRUMENT PANEL
22
A1203020401
KNOB , NO LONGER AVAILABLE
25
A0009971881
GROMMET
999
A1213000225
LEVER FOR RELEASE SPRING
999
A1213000620
CONTROL SHAFT
999
A1213010701
ACCELERATOR PEDAL
999
A6213000120
CONTROL SHAFT , Replaced By: A1213000620
