Поз.
Артикул
Описание
5
DIFFERENTIAL GEAR
5
DIFFERENTIAL GEAR
8
AXLE HOUSING DIFFERENTIAL GEAR
8
AXLE HOUSING , EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO REAR AXLE730499, Replaced By: A3883500162
8
AXLE HOUSING , Replaced By: A3953504620
11
CYLINDRICAL PIN , Replaced By: N000007008101
14
SCREW DIFFERENTIAL GEAR BEARING
17
PIN DIFFERENTIAL GEAR BEARING
20
SNAP RING
80
HOUSING (PINION HOUSING)
80
HOUSING , Replaced By: A3463530807, +001N000906020003
110
SPACER WASHER PINION HOUSING, AS REQUIRED 1.50 MM
110
SPACER WASHER AS REQUIRED 1.00 MM
110
SPACER WASHER AS REQUIRED 0.50 MM
110
SPACER WASHER PINION HOUSING, AS REQUIRED 0.35 MM
110
SPACER WASHER PINION HOUSING, AS REQUIRED 0.20 MM
110
SPACER WASHER AS REQUIRED 0.15 MM
110
SPACER WASHER AS REQUIRED 0.10 MM
110
SPACER WASHER DIFFERENTIAL GEAR,AS REQUIRED 1.50 MM
110
SPACER WASHER DIFFERENTIAL GEAR,AS REQUIRED 1.00 MM
110
SPACER WASHER DIFFERENTIAL GEAR,AS REQUIRED 0.50 MM
110
SPACER WASHER DIFFERENTIAL GEAR,AS REQUIRED 0.35 MM
110
SPACER WASHER DIFFERENTIAL GEAR,AS REQUIRED 0.20 MM
110
SPACER WASHER DIFFERENTIAL GEAR,AS REQUIRED 0.15 MM
110
SPACER WASHER DIFFERENTIAL GEAR,AS REQUIRED 0.10 MM
113
SEAL RING PINION HOUSING TO AXLE HOUSING
116
SCREW TRANSMISSION CASE TO TRANSMISSION CASE
116
SCREW BATTERY CASE TO SIDE MEMBER
119
HEXAGON HEAD BOLT COVER TO DIFFERENTIAL CASE M12X1.5X85
119
SCREW BRACKET TO BRACKET
122
COVER
125
GASKET SHIFTING CYLINDER TO INTERMEDIATE FLANGE
128
SCREW PLUG SOCKET TO FRAME
