Поз.
Артикул
Описание
223
AIR CLEANER ,4 938204
226
FILTER ELEMENT
229
NUT
232
WASHER FELT
265
PIPE ELBOW (INTAKE PIPE),4 938204
268
GASKET INTAKE PIPE TO AIR CLEANER,4 938204
271
NUT , Replaced By: N913004008001
271
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
271
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
271
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
274
BOOT , Replaced By: A6205200296
274
BOOT AIR INTAKE
277
STRAINER BOOT
277
STRAINER , Replaced By: A6205280103
280
CLAMP BOOT TO INTAKE PIPE
283
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
283
SCREW , Replaced By: N304017008027
286
WASHER EXHAUST MUFFLER TO STRAP
286
WASHER , Replaced By: N000125008443
289
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
289
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
289
NUT , Replaced By: N913004008001
292
BRACKET BOOT
292
BRACKET , Replaced By: A6575280040
295
SCREW BOOT TO BRACKET
298
BRACKET BOOT
301
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
301
SCREW , Replaced By: N304017008016
304
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
304
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
304
NUT , Replaced By: N913004008001
307
SUPPORT BOOT
310
SCREW BRACKET TO SUPPORT
313
WASHER RADIATOR TO RUBBER MOUNTING
313
WASHER , Replaced By: N000125010532
316
NUT STRAP TO BRACKET
316
NUT , Replaced By: N910113010000
319
SCREW EXHAUST PIPE TO BRACKET
322
SCREW BRACKET TO SIDE MEMBER
322
SCREW , Replaced By: N304017010002
325
WASHER RADIATOR TO RUBBER MOUNTING
325
WASHER , Replaced By: N000125010532
328
NUT STRAP TO BRACKET
328
NUT , Replaced By: N910113010000
331
HOSE FROM AIR CLEANER TO CAB CONSOLE
334
CLAMP HOSE TO CAB CONSOLE AND TO ENGINE CONNECTION
334
CLAMP HOSE TO AIR CLEANER AND CAB CONSOLE 130-150X13 MM, Replaced By: N000000005892
334
CLAMP , Replaced By: N000000000678
341
THREADED INSERT
343
SEAL RING INTAKE PIPE TO CAB CONSOLE,5 088424
349
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
349
SPRING WASHER , Replaced By: N000137008212
352
HOSE FROM CAB CONSOLE TO ENGINE CONNECTION
352
HOSE , Replaced By: A0010941182
355
CLAMP HOSE TO CAB CONSOLE AND TO ENGINE CONNECTION
355
CLAMP HOSE TO AIR CLEANER AND CAB CONSOLE 130-150X13 MM, Replaced By: N000000005892
355
CLAMP , Replaced By: N000000000678
358
PIPE ELBOW (INTAKE PIPE)
361
THREADED INSERT ,5 462573
364
GASKET INTAKE PIPE TO ENGINE
364
GASKET , Replaced By: A4421411480
367
SCREW HOLLOW RUBBER SPRING TO CAB,5 956657
367
SCREW PIPE ELBOW TO BRACKET M 10X50
367
SCREW , Replaced By: N304017010053
367
SCREW , Replaced By: N304017010030
367
SCREW BRACKET TO SUPPORT
370
SPRING WASHER STEERING COLUMN BRACKET TO CAB
373
NUT STRAP TO BRACKET
373
NUT , Replaced By: N910113010000
999
SEAL RING INTAKE PIPE TO CAB CONSOLE,5 088425
999
CAP OIL REFILLING
999
CAP OIL REFILLING
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
WASHER COMPRESSED AIR LINE TO BRACKET
