Поз.
Артикул
Описание
10
CONSOLE LEFT
15
CONSOLE RIGHT
20
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
24
SCREW CROSS MEMBER TO FRONT SPRING REAR BRACKET M 14X1.5X70
24
SCREW , Replaced By: N308676014014
24
SCREW , Replaced By: N000961014158
28
SCREW BEARING TO TRANSFER CASE M 14X140
35
BEARING RUBBER MOUNT
39
SPACER TUBE RUBBER MOUNT
45
BRACKET TRANSFER CASE TO FRAME,LEFT
50
BRACKET TRANSFER CASE TO FRAME,RIGHT
56
SCREW BEARING BRACKET TO REAR AXLE M 16X1.5X40
56
SCREW , Replaced By: N308676016013
60
NUT CONSOLE TO SUPPORT
60
NUT , Replaced By: N910113016001
65
BEARING TRANSFER CASE CONSOLE
65
BEARING , Replaced By: A6212850403
65
BEARING TRANSFER CASE CONSOLE
65
BEARING , Replaced By: A6212850403
70
SHIM BEARING BRACKET TO BRACKET
74
SHIM BEARING BRACKET TO BRACKET
80
SCREW BEARING BRACKET TO REAR AXLE M 16X1.5X50
80
SCREW BEARING BRACKET TO REAR AXLE M 16X1.5X50
80
SCREW , Replaced By: N308676016007
84
SCREW RUBBER MOUNTING TO SUPPORTING ARM M 16X1.5X80
88
NUT CONSOLE TO SUPPORT
88
NUT , Replaced By: N910113016001
95
SCREW RUBBER MOUNTING TO BEARING M 16X1.5X200
99
NUT CONSOLE TO SUPPORT
99
NUT , Replaced By: N910113016001
105
BRACKET ROD TO TRANSFER CASE
110
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
114
SCREW ROD TO TRANSFER CASE M 14X65
114
SCREW , Replaced By: N308676014013
120
SPACER TUBE PULL ROD TO TRANSFER CASE AND TO SIDE MEMBER
125
WASHER MOUNTING USED FOR FRAME CONNECTION PARTS
125
WASHER , Replaced By: N007349013005
129
HEXAGON HEAD BOLT. SCREW PULL ROD TO TRANSFER CASE AND TO SIDE MEMBER
129
SCREW , Replaced By: N308765012003
133
NUT SUPPORT TO SIDE MEMBER
140
ROD TRANSFER CASE TO FRAME
141
JOINT
142
CLAMP
142
CLAMP , Replaced By: A0009957044
145
BRACKET ROD TO SIDE MEMBER
145
BRACKET ROD TO SIDE MEMBER
150
HEXAGON HEAD BOLT. SCREW ENGINE MOUNTING TO SUPPORT,ON CLUTCH END M 14X30
150
SCREW , Replaced By: N308676014003
154
NUT STEERING SUPPORT TO FRAME
154
NUT , Replaced By: N910113014000
159
VALVE 3/2-WAY VOSS
159
VALVE 3/2-WAY KNORR
159
VALVE 3/2-WAY WABCO
159
VALVE 3/2-WAY BOSCH
165
SPRING INSIDE WABCO
171
SEAL RING INSIDE WABCO
177
SEAL RING TOP WABCO
183
UNIT IDENTIFICATION PLATE LONGITUDINAL DIFFERENTIAL LOCK
189
WASHER AT TWO-WAY VALVE
195
NUT 4/3-WAY VALVE TO SUBSTRUCTURE
201
VALVE 4/3-WAY, TRANSFER CASE ACTUATION WABCO
201
VALVE 4/3-WAY, TRANSFER CASE ACTUATION BOSCH
207
REPAIR KIT 4/3-WAY VALVE WABCO
213
UNIT IDENTIFICATION PLATE ON-ROAD/OFF-ROAD SPEED
219
WASHER AT TWO-WAY VALVE
225
NUT 4/3-WAY VALVE TO SUBSTRUCTURE
231
HANDLE VALVE
237
HOLLOW SCREW HEATING CONNECTION
243
SEAL RING LINE CONNECTION
249
HOLLOW SCREW LINE CONNECTION
255
HOLLOW SCREW LINE CONNECTION
255
HOLLOW SCREW LINE CONNECTION
261
SEAL RING LINE CONNECTION
261
SEAL RING LINE CONNECTION
267
PLASTIC PIPE RISING PIPE 4X6 MM
267
PLASTIC PIPE RISING PIPE 4X6 MM
267
PLASTIC PIPE RISING PIPE 4X6 MM
267
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
270
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
273
BANJO UNION HOSE WIDTH, / I.D., 4/12 MM
279
BANJO UNION HOSE WIDTH, / I.D., 4/10 MM
285
LOOM TIE LINE MOUNTING 280 MM
291
HOLLOW SCREW LINE CONNECTION
297
HOLLOW SCREW HEATING CONNECTION
303
SEAL RING LINE CONNECTION
999
BUSHING
999
BUSHING
999
RUBBER MOUNTING , Replaced By: A0002420250
999
BRACKET LINE MOUNTING
999
SCREW
999
HEXAGON NUT
999
NUT , Replaced By: N910113010002
