Главная
›
Mercedes
›
BUS
›
O530 - CITARO 12M, 2-TUERER
›
628.083
›
54 ELECTRICAL EQUIPMENT AND INSTRUMENTS
›
330 ENGINE ELECTRIC CABLE & COOLING SYSTEM IL. 1
Mercedes N304032004002 - Гайка
O530 - CITARO 12M, 2-TUERER 628.083
54 ELECTRICAL EQUIPMENT AND INSTRUMENTS - 330 ENGINE ELECTRIC CABLE & COOLING SYSTEM IL. 1
Поз.
Артикул
Описание
137
A0007631561
HOSE , TO BE ADAPTED DURING ASSEMBLY
140
A6287630208
BEARING TOP, ORDER ADDITIONALLY:A6289920203
142
A6287630037
SUPPORTING ARM TOP
143
A6289900029
SCREW
175
A6287630008
COVERING
176
N000000001552
HEXALOBULAR BOLT MOUNTING PARTS M4X16
177
N304032004002
NUT BOOT TO AIR DUCT AND TO AIR CLEANER
205
A6289920203
BUSHING
220
A6287630137
SUPPORTING ARM
225
N000000003419
SCREW
230
N000000003428
SCREW , Replaced By: N000000005662
230
N000000005662
NUT SUPPORT TO FRAME
230
N913023014003
NUT BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER
235
A0079903304
SCREW
280
A0018204297
POTENTIOMETER
281
A0139972845
SEAL RING
282
A6287600128
BRACKET
283
A0079903404
SCREW
284
A0009901415
SCREW
800
A0009921403
BUSHING
803
A0109900104
SCREW W SOCKET DRIVEM8X20
806
N304017004003
HEXAGON HEAD BOLT BOTTOM
863
A6287600864
PILLAR
866
N910105008052
SCREW. HEXAGON HEAD BOLTM8X16
869
A0019909620
SCREWM5X12 TX25
872
N005401314000
BALL
875
N304035010001
NUT
878
N910105010026
HEXAGON HEAD BOLTM10X20, Replaced By: N910105010006
884
A6287630608
COVERING
887
A6287630920
MOUNTING
890
A6287631020
MOUNTING
893
A6287631120
MOUNTING
896
A6287631220
MOUNTING
899
A6287631320
MOUNTING
902
A6287631837
SUPPORTING ARM
908
A6287660417
MOUNTING
911
A6287660717
MOUNTING
914
A6287660719
PLATE
999
A0007280090
WELT , Replaced By: A0079896185
999
A0007300497
EDGE GUARD SECTION , Replaced By: A0099875751
999
A0029905778
CONNECTOR2X1, 500MM
999
A6287201654
SEAL LEFT BOTTOM
999
A6287201754
SEAL RIGHT BOTTOM
