Главная
Mercedes
CAR
E 300 TURBODIESEL
124.133 200-320 FROM 10/92, 200D-300D FROM 7/93
32 SPRINGS,SUSPENSION AND HYDRAULICS
015 SPRINGS AND SUSPENSION,FRONT IL. 2

Mercedes N000125008443 - ШАЙБА

E 300 TURBODIESEL 124.133 200-320 FROM 10/92, 200D-300D FROM 7/93

32 SPRINGS,SUSPENSION AND HYDRAULICS - 015 SPRINGS AND SUSPENSION,FRONT IL. 2

Поз.
Артикул
Описание
5
A1244604516
STEER. COLUMN JACKET TUBE OUTSIDE, ONLY APPLICABLE TO ELECTRICALLY ADJUSTABLE STEERING COLUMN
5
A1244602716
STEER. COLUMN JACKET TUBE OUTSIDE, ONLY APPLICABLE TO ELECTRICALLY ADJUSTABLE STEERING COLUMN
8
N000912006097
SCREWM 6X16
8
N000912006066
SCREW BEARING BRACKET TO TRANSMISSION
11
N000433006405
WASHER BRACKET TO HEAT SHIELD
14
A1244621220
STEER.COLUMN JACKET TUBE INSIDE, ONLY APPLICABLE TO ELECTRICALLY ADJUSTABLE STEERING COLUMN
14
A1264621720
STEER.COLUMN JACKET TUBE INSIDE, ONLY APPLICABLE TO ELECTRICALLY ADJUSTABLE STEERING COLUMN
14
A1264621620
STEER.COLUMN JACKET TUBE , Replaced By: A1244621220
17
N000933006103
SCREW , Replaced By: N304017006018
17
N304017006018
SCREW COVER PLATE TO COVER PLATE M 6 X 12
20
A1294620639
BRACKET , ONLY APPLICABLE TO ELECTRICALLY ADJUSTABLE STEERING COLUMN C 014018 J 016700
20
A1244622539
BRACKET BLINKER SWITCH, ONLY APPLICABLE TO ELECTRICALLY ADJUSTABLE STEERING COLUMN
23
N007985006139
SCREW OIL TANK TO BRACKET
26
N000433006405
WASHER BRACKET TO HEAT SHIELD
62
A1269931226
DISC SPRING , Replaced By: A1244600422
62
A1264620362
THRUST WASHER , Replaced By: A1244600422
62
A1244600422
CLAMPING PIECE
68
N000472021000
LOCK RING21 MM
71
A1264620571
SCREW
74
A1264600325
GEARING
77
A1264622274
PIN
80
N912001008000
LOCK HOSE FASTENING
83
N000125008418
WASHER , Replaced By: N000125008443
83
A6210710152
SPACER WASHER , Replaced By: N000125008418
83
N000125008443
WASHER EXHAUST MUFFLER TO STRAP
104
A0019907212
SCREW SHIM TO LEAF SPRING
104
N000912006175
SCREW , Replaced By: A0019907212
104
N000912006025
SCREW , Replaced By: N000912006175
