Поз.
Артикул
Описание
5
FOOT PARKING BRAKE PEDAL ASSEMBLY
5
PARKING BRAKE PEDAL ASSEMBLY, 08873620040907
10
PAD FOOT OPERATED PARKING BRAKE
10
PAD PEDAL
13
PUSH SPRING
16
SWITCH HAND BRAKE CONTROL
19
SCREW. HEXALOBULAR BOLT COVER TO MOUNTING FRAME M5X12
22
SPRING
25
HEXALOBULAR BOLT PLATE CENTER MOUNTING M8X25
40
CLAMP LINE MOUNTING SA 088202/01
43
NUT SPRING-LOADED PUSH ROD
46
END PIECE (EXPANSION VALVE) 5 MM
49
BOLT. SCREW TAKE-UP DEVICE, F 136790(COUPE) T 000731(COUPE), T 054272(CABRIO) EXEPT ON VEHICULES WITH CODE 800 ALSO INSTALLED IN VEHICLE TO T 000730(COUPE), T 054271(CABRIO), F 136789(COUPE) WITH CODE 801
58
BRAKE CABLE
61
HANDLE RELEASE HANDLE FOOT-OPERATED PARKING BRAKE, 7C45QFT639A1007 DEEP GREY
64
GUIDE
67
STOP ARMREST
70
73
EDGE PROTECTION AT CROSS MEMBER
73
STOP PLUG27X41MM
76
BOWDEN CABLE ADJUSTMENT
90
BRAKE CABLE RIGHT
90
BRAKE CABLE
96
CYLINDER PIN. PIN
99
BRACKET BRAKE CABLE
103
RIVET REFLECTOR TO BRACKET
106
PLUG HOUSING UNIPOLAR
