Поз.
Артикул
Описание
434
RESERVOIR40L,246 MM,8.5 BAR
434
RESERVOIR , Replaced By: A0034322301
437
STRAP SERVICE BRAKE AIR RESERVOIR
440
BASE AIR RESERVOIR,STRAP
443
SCREW END PIECE TO EXHAUST PIPE M 10X25
446
NUT STRAP TO BRACKET
446
NUT , Replaced By: N910113010000
449
RESERVOIR ,5 563826
449
RESERVOIR ,5 934167, Replaced By: A0034321401
452
BRACKET AIR RESERVOIR TO APPARATUS SUPPORT
455
SCREW BRACKET TO APPARATUS SUPPORT
455
SCREW , Replaced By: A0069909301
458
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
458
NUT , Replaced By: N913004008001
461
STRAP SPRING-LOADED BRAKE AIR RESERVOIR
464
NUT STRAP TO BRACKET
464
NUT , Replaced By: N910113010000
467
COMPRESSED AIR RESERVOIR. RESERVOIR6 L, TO VOSS 232, FOR VEHICLES WITH VOSS 230 CONNECTOR:ADD. MOUNT FITTING "A 004 997 82 72" WITH O-RING "A 000 987 04 46" AND THRUST RING "A 000 997 02 03" TO AIR RESERVOIR
467
RESERVOIR , Replaced By: A0054322001, +001A0009870446, +001A0009940203, +001A0049978272
467
RESERVOIR ,5 934167, Replaced By: A0034320601
473
BASE AIR RESERVOIR TO RIGHT SIDE MEMBER, INSIDE
476
HEXALOBULAR BOLT. SCREW MANUAL PUMP BRACKET TO FENDER BRACKET
476
SCREW. HEXAGON HEAD BOLT , Replaced By: N910143008005
476
SCREW BRACKET TO SIDE MEMBER
476
SCREW , Replaced By: N304017008040
476
SCREW PIPE CLAMP
476
SCREW , Replaced By: N304017008021
479
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
479
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
479
NUT , Replaced By: N913004008001
482
LOCK (PROTECTION AGAINST TORSION),5 934167
485
FITTING AIR RESERVOIR,CONNECTION: "11"
485
FITTING AIR RESERVOIR,CONNECTION: "11"
488
FITTING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
489
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
489
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
491
T-FITTING OVERFLOW VALVE,CONNECTION: "12"
492
FITTING , Replaced By: A0009907771
497
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "21"
497
SCREW PLUG , Replaced By: N000908022011
500
THRUST RING CHECK VALVE TO AIR RESERVOIR
500
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
503
O-RING CHECK VALVE TO AIR RESERVOIR
509
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
512
HOLLOW SCREW HEATING CONNECTION
515
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
518
SEAL RING LINE CONNECTION
521
VALVE DRAIN, Replaced By: A0004322107
521
VALVE. DRAIN VALVE DRAIN
521
VALVE. DRAIN VALVE DRAIN
521
VALVE DRAIN, Replaced By: A0004322107
521
VALVE DRAIN, Replaced By: A0004322407
524
THRUST RING CHECK VALVE TO AIR RESERVOIR
524
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
527
O-RING CHECK VALVE TO AIR RESERVOIR
999
SEAL RINGKNORR
999
ADAPTER FITTING LINE CONNECTION TO ENGINE
999
REPAIR KIT , Replaced By: A0014308460, +001A0004303506
999
REPAIR KIT BRAKE POWER REGULATOR TO 002 431 05 12,KNORR
999
REPAIR KIT PRESSURE REGULATOR KNORR
999
REPAIR KIT , Replaced By: A0024209524, +002A0024209424
999
REPAIR KIT , Replaced By: A0004308206
999
REPAIR KITTO 002 431 06 05,WABCO
999
RING DRAIN VALVE TO 000 432 08 07, NOT USED
999
CONNECTOR REPAIR SIZE
999
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
999
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
999
SCREW. UNION SCREW LINE CONNECTION
999
GASKET KITBOSCH
999
GASKET KITWABCO
999
GASKET KITBOSCH
999
GASKET KITKNORR
999
VALVE (REGULATING VALVE)
999
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION
999
PRESSURE REGULATORKNORR
999
REPAIR KIT , Replaced By: A0024301560
999
REPAIR KITTO 002 430 98 81,99 81,KNORR
999
REPAIR KITTO 001 430 66 81,001 430 67 81,KNORR
999
SEAL RING TOP WABCO
999
SPRING INSIDE WABCO
999
SEAL RING INSIDE WABCO
999
NUT 4/3-WAY VALVE TO SUBSTRUCTURE
999
UNIT IDENTIFICATION PLATE SYMBOL: LONGITUDINAL DIFFERENTIAL LOCK
999
ADHESIVE FOIL GUIDE SIGN
999
BEARING BRACKET WHEEL CYLINDER, IN CASE OF STEEL AXLE
999
BRACKET , Replaced By: A6205243040
999
BRACKET BRACKET TO CROSS MEMBER
999
WASHER AT TWO-WAY VALVE
999
STRAP AIR RESERVOIR TO RIGHT SIDE MEMBER, INSIDE
999
REPAIR KIT. TS SEALING RING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 22
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
WASHER COMPRESSED AIR LINE TO BRACKET
999
WASHER , Replaced By: N000125008443
999
WASHER EXHAUST MUFFLER TO STRAP
999
NUT COMPRESSED AIR LINE THRU FRAME,5 395034
999
SCREW BRACKET TO SIDE MEMBER
999
WASHER STRAP TO SUPPORT
999
SEAL RING LINE CONNECTION
999
SEAL RING LINE CONNECTION
999
NUT BRACKET TO SIDE MEMBER
999
NUT , Replaced By: N910113014001
999
HOLLOW SCREW LINE CONNECTION
999
HOLLOW SCREW FITTING RELAY VALVE,CONNECTION "20",LEFT
999
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
