Поз.
Артикул
Описание
80
ELECTRIC CABLE
80
PARTS KIT FUEL GAUGE SENDER UNIT, THIS CABLE HARNESS IS A COMPONENT OF FRAME MOUNTED CABLE HARNESS ASSEMBLY AND CAN BE MADE AVAILABLE AS A SPARE ATTENTION: WHEN PLACING ORDERS, PLEASE QUOTE VEHICLE IDENT NO. ONLY IF FRAME MOUNTED CABLE HARNESS IS REQUIRED AS AN ASSEMBLYK 171434
80
CABLE HARNESS , Replaced By: A0025402381, +001A0005467735
80
ELECTRIC CABLE , Replaced By: A6515406327
83
CABLE HARNESS IDLING/BACK-UP-LIGHT SWITCH, THIS CABLE HARNESS IS A COMPONENT OF FRAME MOUNTED CABLE HARNESS ASSEMBLY AND CAN BE MADE AVAILABLE AS A SPARE ATTENTION: WHEN PLACING ORDERS, PLEASE QUOTE VEHICLE IDENT NO. ONLY IF FRAME MOUNTED CABLE HARNESS IS REQUIRED AS AN ASSEMBLY
83
CABLE HARNESS FROM MODULE TO TRANSMISSION GEAR CLUSTER INDICATOR SWITCH, THIS CABLE HARNESS IS A COMPONENT OF FRAME MOUNTED CABLE HARNESS ASSEMBLY AND CAN BE MADE AVAILABLE AS A SPARE ATTENTION: WHEN PLACING ORDERS, PLEASE QUOTE VEHICLE IDENT NO. ONLY IF FRAME MOUNTED CABLE HARNESS IS REQUIRED AS AN ASSEMBLY
99
ELECTRIC CABLE CONNECTION JUNCTION PLATE TO PLUG FOR PLUG CONNECTION CAB/CHASSIS 3200 MM,K 152382
104
CABLE HARNESS FROM MODULE TO LONGITUDINAL DIFFERENTIAL LOCK SWITCH AT TRANSFER CASE, THIS CABLE HARNESS IS A COMPONENT OF FRAME MOUNTED CABLE HARNESS ASSEMBLY AND CAN BE MADE AVAILABLE AS A SPARE ATTENTION: WHEN PLACING ORDERS, PLEASE QUOTE VEHICLE IDENT NO. ONLY IF FRAME MOUNTED CABLE HARNESS IS REQUIRED AS AN ASSEMBLY
104
CABLE HARNESS , THIS CABLE HARNESS IS A COMPONENT OF FRAME MOUNTED CABLE HARNESS ASSEMBLY AND CAN BE MADE AVAILABLE AS A SPARE ATTENTION: WHEN PLACING ORDERS, PLEASE QUOTE VEHICLE IDENT NO. ONLY IF FRAME MOUNTED CABLE HARNESS IS REQUIRED AS AN ASSEMBLY, Replaced By: A6255403009
107
CABLE HARNESS PARKING BRAKE SWITCH, THIS CABLE HARNESS IS A COMPONENT OF FRAME MOUNTED CABLE HARNESS ASSEMBLY AND CAN BE MADE AVAILABLE AS A SPARE ATTENTION: WHEN PLACING ORDERS, PLEASE QUOTE VEHICLE IDENT NO. ONLY IF FRAME MOUNTED CABLE HARNESS IS REQUIRED AS AN ASSEMBLY
110
CABLE HARNESS BRAKE PRESSURE CONTROL,CIRCUITS I & II, THIS CABLE HARNESS IS A COMPONENT OF FRAME MOUNTED CABLE HARNESS ASSEMBLY AND CAN BE MADE AVAILABLE AS A SPARE ATTENTION: WHEN PLACING ORDERS, PLEASE QUOTE VEHICLE IDENT NO. ONLY IF FRAME MOUNTED CABLE HARNESS IS REQUIRED AS AN ASSEMBLYK 062140
110
ELECTRIC CABLE BRAKE PRESSURE CONTROL,CIRCUIT III, THIS CABLE HARNESS IS A COMPONENT OF FRAME MOUNTED CABLE HARNESS ASSEMBLY AND CAN BE MADE AVAILABLE AS A SPARE ATTENTION: WHEN PLACING ORDERS, PLEASE QUOTE VEHICLE IDENT NO. ONLY IF FRAME MOUNTED CABLE HARNESS IS REQUIRED AS AN ASSEMBLY
113
ELECTRIC CABLE FROM MODULE TO TAIL LIGHT PLUG CONNECTION, THIS CABLE HARNESS IS A COMPONENT OF FRAME MOUNTED CABLE HARNESS ASSEMBLY AND CAN BE MADE AVAILABLE AS A SPARE ATTENTION: WHEN PLACING ORDERS, PLEASE QUOTE VEHICLE IDENT NO. ONLY IF FRAME MOUNTED CABLE HARNESS IS REQUIRED AS AN ASSEMBLY FROMIDENT NO. 5 909053, 8-POLE, USED WITHOUT ZA 95416, 654.4 / 654.5 / 657.5 FROMIDENT NO. 5 922046, 8-POLE, USED WITHOUT ZA 95416, 625/ 653/ 654.0/654.1/ 657.1/ 659 FROM IDENT NO. 5 929745, 8-POLE, USED WITHOUT ZA 95416,650/ 651/ 656/ 658 AND 655 FOR ENGINE 442.997 FROMIDENT NO. 5 936425, 8-POLE, USED WITHOUT ZA 95416, 652/ 655
113
CABLE HARNESS FROM MODULE TO TAIL LIGHT PLUG CONNECTION, THIS CABLE HARNESS IS A COMPONENT OF FRAME MOUNTED CABLE HARNESS ASSEMBLY AND CAN BE MADE AVAILABLE AS A SPARE ATTENTION: WHEN PLACING ORDERS, PLEASE QUOTE VEHICLE IDENT NO. ONLY IF FRAME MOUNTED CABLE HARNESS IS REQUIRED AS AN ASSEMBLY UP TO IDENT NO. 5 936692 OR ZA 95416,9-POLE
113
CABLE HARNESS FROM MODULE TO TAIL LIGHT PLUG CONNECTION, THIS CABLE HARNESS IS A COMPONENT OF FRAME MOUNTED CABLE HARNESS ASSEMBLY AND CAN BE MADE AVAILABLE AS A SPARE ATTENTION: WHEN PLACING ORDERS, PLEASE QUOTE VEHICLE IDENT NO. ONLY IF FRAME MOUNTED CABLE HARNESS IS REQUIRED AS AN ASSEMBLY UP TO IDENT NO. 5 936692 OR ZA 95416,9-POLE
113
ELECTRIC CABLE FROM MODULE TO TAIL LIGHT PLUG CONNECTION, THIS CABLE HARNESS IS A COMPONENT OF FRAME MOUNTED CABLE HARNESS ASSEMBLY AND CAN BE MADE AVAILABLE AS A SPARE ATTENTION: WHEN PLACING ORDERS, PLEASE QUOTE VEHICLE IDENT NO. ONLY IF FRAME MOUNTED CABLE HARNESS IS REQUIRED AS AN ASSEMBLY FROMIDENT NO. 5 909053, 8-POLE, USED WITHOUT ZA 95416, 654.4 / 654.5 / 657.5 FROMIDENT NO. 5 922046, 8-POLE, USED WITHOUT ZA 95416, 625/ 653/ 654.0/654.1/ 657.1/ 659 FROM IDENT NO. 5 929745, 8-POLE, USED WITHOUT ZA 95416,650/ 651/ 656/ 658 AND 655 FOR ENGINE 442.997 FROMIDENT NO. 5 936425, 8-POLE, USED WITHOUT ZA 95416, 652/ 655
119
BRACKET LINE TO FRONT PANEL
122
INSULATING HOSE CABLE PROTECTION
125
BRACKET LOWER PART, INSULATING HOSE TO CAB FLOOR
128
GASKET BRACKET,BOTTOM
131
BRACKET UPPER PART, INSULATING HOSE TO CAB FLOOR
134
GASKET BRACKET,TOP
137
SHEET METAL SCREW BRACKET TO CAB FLOOR
140
LOCK BRACKET TO CAB FLOOR
143
BRACKET INSULATING HOSE GUIDE
143
BRACKET INSULATING HOSE GUIDE
147
SCREW BRACKET TO CROSS CONNECTION STRUT
147
SCREW , Replaced By: N304017008034
149
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
149
NUT , Replaced By: N913004008001
149
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
152
CAP TO LOCK ELECTRIC LEAD-IN
155
GASKET TO LOCK ELECTRIC LEAD-IN
158
BRACKET TO LOCK ELECTRIC LEAD-IN
161
TAPPING SCREW COVER AND BRACKET TO CAB CORNER PILLAR
161
SHEET METAL SCREW , Replaced By: N000000000463
161
SHEET METAL SCREW , Replaced By: N007981004257
164
WASHER , Replaced By: N000433005304
164
WASHER BOOT TO CAB FLOOR
167
TREENAIL BRACKET TO FIRE WALL, Replaced By: A6399980185
167
TREENAIL BRACKET TO FIRE WALL
170
LOCK COVER AND BRACKET TO CAB CORNER PILLAR
212
SWITCH SUPPLY PRESSURE
215
SEAL RING LINE CONNECTION
221
SWITCH SUPPLY PRESSURE,5 966147
222
SWITCH (PRESSURE SWITCH) 5,5 BAR
227
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
236
SCREW BRACKET TO SPRING BRACKET AND TO CROSS MEMBER,5 953233K 027550
242
NUT , Replaced By: N910113014001
242
NUT BRACKET TO SIDE MEMBER
243
ANGLE LINE MOUNTING
244
WASHER , Replaced By: A3609902340
244
WASHER BRACKET TO LEFT SIDE MEMBER
245
SCREW , Replaced By: N304017008034
245
SCREW BRACKET TO CROSS CONNECTION STRUT
246
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
246
NUT , Replaced By: N913004008001
246
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
265
ELECTRIC CABLE FROM FUSE BOX TO CENTRAL LUBRICATION CONTROL UNIT
265
ELECTRIC CABLE , Replaced By: A6555401937
265
ELECTRIC CABLE FROM FUSE BOX TO CENTRAL LUBRICATION CONTROL UNIT
266
PLUG. BLIND PLUG DUMMY PLUG FOR SENSOR CABLE
267
SCREW SENSOR CABLE MOUNTING
267
SCREW , Replaced By: N910106006008
268
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
268
WASHER COMPRESSED AIR LINE TO BRACKET
269
ELECTRIC CABLE TAIL LAMP, FROMIDENT NO. 5 936693, 8-POLE, USED WITHOUT ZA 95416K 057592
269
ELECTRIC CABLE , UP TO IDENT NO. 5 936692 OR ZA 95416,9-POLE, Replaced By: A6555401036
269
ELECTRIC CABLE , UP TO IDENT NO. 5 928579 OR ZA 95416,9-POLE, Replaced By: A6555401036
269
ELECTRIC CABLE , Replaced By: A6555401036
269
ELECTRIC CABLE TAIL LAMP, UP TO IDENT NO. 5 936692 OR ZA 95416,9-POLE
270
ELECTRIC CABLE USED W/ADDITIONAL TAIL LAMP, FROMIDENT NO. 5 936693, 8-POLE, USED WITHOUT ZA 95416
270
ELECTRIC CABLE USED W/ADDITIONAL TAIL LAMP, UP TO IDENT NO. 5 936692 OR ZA 95416,9-POLE
271
ELECTRIC CABLE FROM CABLE HARNESS PLUG-CONNECTION TO TAIL LAMP PLUG-CONNECTION, UP TO IDENT NO. 5 909052 OR ZA 95416, 9-POLE, 654.4 / 654.5 / 657.5 UP TO IDENT NO. 5 922045 OR ZA 95416, 9-POLE, 625/ 653/ 654.0/ 654.1/ 657.1/ 659 UP TO IDENT NO. 5 929744 OR ZA 95416,9-POLE, 650/ 651/ 656/ 658 AND 655 FOR ENGINE 442.997 UP TO IDENT NO. 5 936424 OR ZA 95416, 9-POLE, 652/ 655
271
ELECTRIC CABLE FROM CABLE HARNESS PLUG-CONNECTION TO TAIL LAMP PLUG-CONNECTION, FROMIDENT NO. 5 909053, 8-POLE, USED WITHOUT ZA 95416, 654.4 / 654.5 / 657.5 FROMIDENT NO. 5 922046, 8-POLE, USED WITHOUT ZA 95416, 625/ 653/ 654.0/654.1/ 657.1/ 659 FROM IDENT NO. 5 929745, 8-POLE, USED WITHOUT ZA 95416,650/ 651/ 656/ 658 AND 655 FOR ENGINE 442.997 FROMIDENT NO. 5 936425, 8-POLE, USED WITHOUT ZA 95416, 652/ 655
999
GASKET ELECTRIC CABLE THRU CAB FLOOR
999
ELECTRIC CABLE CAB ROOF, FOR USE WITH SHORT MERCEDES-BENZ CAB5 563624 NOT USED
