Главная
›
Mercedes
›
TRUCK
›
1717 K
›
652.116
›
29 PEDAL ASSEMBLY
›
090 CLUTCH AND BRAKE PEDAL ASSEMBLY
Mercedes N304017006016 - Винт M 6 X 16 8.8
1717 K 652.116
29 PEDAL ASSEMBLY - 090 CLUTCH AND BRAKE PEDAL ASSEMBLY
Поз.
Артикул
Описание
12
A6595400042
PLATE
24
A6555400142
PLATE ,5 551281
24
A6555400442
PLATE ,5 551282
36
A6595450482
PLATE
36
A6555450182
PLATE ,5 590319
48
A6595400242
PLATE , Replaced By: A6595400442
48
A6595400442
PLATE ,5 590320
60
A6595400342
PLATE
144
A0019880942
CATCH. FASTENER LOWER PART
156
N000933006183
SCREW , Replaced By: N304017006016
156
N304017006016
SCREW PUMP TO BRACKET
168
N007985006501
SCREW APPARATUS PLATE M 6X10,5 551281
180
N009021006205
WASHER , Replaced By: N009021006208
180
N009021006208
WASHER COMPRESSED AIR LINE TO BRACKET
192
N912004006102
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
204
A2019901391
NUT RETAINER APPARATUS PLATE,5 715400
216
A6555402073
BRACKET AT CAB REAR PANEL,5 715401
