Поз.
Артикул
Описание
5
PLUG SOCKET FROM REAR JUNCTION BOX TO TRAILER PLUG SOCKET
8
ELECTRIC CABLE FROM REAR JUNCTION BOX TO TRAILER PLUG SOCKET
11
PLUG SOCKET 13-POLE
14
PLUG SOCKET 13-POLE
17
PLUG
17
PLUG
20
SEAL RING ELECTRIC CABLE TO PLUG SOCKET
23
NUT ELECTRIC CABLE TO PLUG SOCKET
26
BOOT
29
MOLDED PIECE PLUG SOCKET TO BRACKET BEHIND CAB
32
LOCK
35
GROMMET CABLE CONNECTOR
35
GROMMET CABLE CONNECTOR
38
DIODE
39
BRACKET TRAILER PLUG SOCKET,BRAKE LINE COUPLINGS
40
SCREW SUPPORT TO CROSS MEMBER M 10X28
41
NUT , Replaced By: N910113010000
41
NUT STRAP TO BRACKET
42
WASHER , Replaced By: N000125008443
42
WASHER EXHAUST MUFFLER TO STRAP
44
SCREW , Replaced By: N304017008034
44
SCREW BRACKET TO CROSS CONNECTION STRUT
47
SCREW BRACKET TO CROSS CONNECTION STRUT
47
SCREW , Replaced By: N304017008034
50
NUT , Replaced By: N913004008001
50
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
53
PLUG TRAILER, 13-POLE
56
SWITCH EXHAUST BRAKE,K 251255
59
FITTING CONNECTION TO STOP LIGHT SWITCH
62
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
62
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
65
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "40"
999
FITTING CONNECTION TO STOP LIGHT SWITCH, Replaced By: A3899970272
999
PLUG , Replaced By: A0235453628
