Поз.
Артикул
Описание
5
LOCK BOTTOM, USED WITH CENTRAL LOCKING MECHANISM
5
LOCK LOWER PART,REAR LID
5
LOCK LOWER PART,REAR LID
8
HEXAGON HEAD BOLT
8
SCREW , Replaced By: N910105006002
9
SCREW , Replaced By: N000000001933
9
SCREW FUSE BOX TO SIDE MEMBER,5 097182
11
LOCK UPPER PART
12
LOCK UPPER PART, BURGLARY ALARM SYSTEM
14
PAD
15
PAD LOCK UPPER PART TO REAR LID
17
PLATE
18
PLATE LOCK UPPER PART TO REAR LID
20
SCREW COVER PLATE TO COVER PLATE M 6 X 12
20
SCREW LICENSE PLATE TO BRACKET
20
SCREW , Replaced By: N304017006018
20
SCREW , Replaced By: N304017006020
23
RUBBER BUFFER
26
LOCK , Replaced By: A1267503285
26
LOCK , Replaced By: A1267500585
26
LOCK , Replaced By: A1267500585
26
LOCK WORKSHOP VERSION WITH KEY, ONLY W/CODE 466 (CENTRAL LOCKING MECHANISM)
26
LOCK LESS KEY, USED WITH CENTRAL LOCKING MECHANISM
29
LOCK WORKSHOP VERSION,WITH KEY, WITH CODE 551 (EDW)
29
LOCK
29
LOCK , Replaced By: A1267503385
29
LOCK , Replaced By: A1267502385
29
LOCK , Replaced By: A1267502385
32
ROUND SECTION SEAL RING LOCK TO HOUSING
35
SCREW , Replaced By: N007985005157
35
SCREW BATTERY CABLE MOUNTING AND MAIN CABLE HARNESS MOUNTING
38
MERCEDES STAR REAR LID
38
MERCEDES STAR , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 021 000531 022,023 001113 032,033 000321 036,037 000225, Replaced By: A1267580058
38
MERCEDES STAR REAR LID
41
RUBBER RING
44
NUT
44
NUT , Replaced By: N304032008006
47
GROMMET MERCEDES STAR TO REAR LID
50
HANDLE (GARNISH MOULDING),REAR LID,A 609425 ONLY FOR R.S.A.
51
SCREW , 015 FROM CHASSIS 002102 016 UP TO CHASSIS 000813
52
LOCK HANDLE LEDGE TO REAR LID
75
TYPE DESIGNATION"300 SD"
76
TYPE DESIGNATION"TURBO-DIESEL"
77
GROMMET
