Поз.
Артикул
Описание
4
HOSE LEAK LINE, ORDER BY THE METER
8
CLAMP LEAK LINE TO CONNECTOR AT ENGINE
10
CLAMP LEAK LINE TO CONNECTOR AT ENGINE
10
LOOM TIE FUEL LINE TO SENDER UNIT
12
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
12
PLASTIC PIPE RISING PIPE 4X6 MM
12
PLASTIC PIPE FUEL SYSTEM 6X2 MM, ORDER BY THE METER
14
SLEEVE LEAK LINE
16
CAP INTAKE MUFFLER FITTING
20
CLAMP RISING PIPE,5 4734955 909351
24
AUXILIARY PUMP FUEL-OIL PUMP
24
AUXILIARY PUMP FUEL-OIL PUMP
24
AUXILIARY PUMP FUEL-OIL PUMP
26
BRACKET PUMP TO FRAME SIDE MEMBER
28
BRACKET FEED LINE AND RETURN LINE
32
CLAMP PUMP TO BRACKET
32
CLAMP PUMP TO BRACKET TO 000 470 84 94
36
SHIM
40
SCREW PUMP TO BRACKET
40
SCREW COVER PLATE TO COVER PLATE M 6 X 12
44
SCREW BRACKET TO CONSOLE
48
NUT HEATING PIPE TO BRACKET
48
NUT CROSS MEMBER TO SIDE MEMBERS
50
INTERMEDIATE PIECE , Replaced By: A0004760125
50
INTERMEDIATE PIECE FUEL LINE,K 223528
52
BRACKET FUEL LINE TO CROSS MEMBER
54
CLIP
56
LOOM TIE LINE MOUNTING
56
LOOM TIE LINE MOUNTING 280 MM
59
VALVE BREATHER LINE,K 169122
59
VALVE BREATHER LINE,K 169122
62
PLASTIC PIPE AERATION, ORDER BY THE METER
65
FITTING (PARTS KIT),LINE RUPTURE
68
SLEEVE LINE CONNECTION
71
CLAMP LINE CONNECTION
71
CLAMP FROM VENT PIPE TO FILLER NECK
74
RUBBER BUFFER TO PLUG THE FREE CONNECTIONS
