Поз.
Артикул
Описание
13
HOSE , Replaced By: A0009872827
13
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
22
FITTING (PARTS KIT),LINE RUPTURE
31
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
31
LOCK RING LINE CONNECTION
31
SEAL RING , Replaced By: A0009940747
40
LOCK LINE CONNECTION
40
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
40
LOCK , Replaced By: A0009945448
49
ELBOW FITTING , Replaced By: A0049905371
49
ELBOW FITTING HOSE WIDTH, 6 MM,TO M22
58
VALVE FRONT AXLE II RELAY VALVE "GRAU", NOT USED
58
VALVE , Replaced By: A0044293844
58
VALVE FRONT AXLE II RELAY VALVE "BOSCH"
58
VALVE FRONT AXLE II RELAY VALVE "WABCO"
67
REPAIR KIT RELAY VALVE "GRAU"
67
REPAIR KIT RELAY VALVE TO 003 429 93 44,WABCO
67
REPAIR KIT RELAY VALVE BOSCH
76
SCREW BRACKET TO SIDE MEMBER
76
SCREW , Replaced By: N304017008040
85
WASHER , Replaced By: N000125008443
85
WASHER EXHAUST MUFFLER TO STRAP
94
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
94
NUT , Replaced By: N913004008001
103
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "21"
103
SCREW PLUG , Replaced By: N000908022011
110
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
119
SCREW. UNION SCREW LINE CONNECTION
119
SCREW. UNION SCREW LINE CONNECTION
128
SCREW. UNION SCREW LINE CONNECTION
128
SCREW. UNION SCREW , Replaced By: A0009973734
999
T-FITTING
999
T-FITTING HOSE WIDTH, / I.D., 6 MM, M 12X1.5, TO M 16
999
ELBOW FITTING HOSE WIDTH, 9 MM,TO M22
999
REPAIR KIT RELAY VALVE TO 004 429 38 44,WABCO
999
FITTING (PARTS KIT),LINE RUPTURE
999
ELBOW FITTING FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTIONS "21,22"
999
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
