Поз.
Артикул
Описание
5
REAR SPRING (SUPPORTING SPRING),5 LEAVES
8
BUSHING SPRING EYE,FRONT AND REAR
11
SHIM BETWEEN THE SPRING LEAVES, TO BE ADAPTED DURING ASSEMBLY
11
SHIM , Replaced By: A9703210184
14
SHIM BETWEEN THE SPRING LEAVES
20
RUBBER BUFFER BETWEEN THE SPRING LEAVES
20
RUBBER BUFFER BETWEEN THE SPRING LEAVES, Replaced By: A3753200844
23
RUBBER BUFFER BETWEEN THE SPRING LEAVES
26
SHIM BETWEEN THE SPRING LEAVES, TO BE ADAPTED DURING ASSEMBLY
26
SHIM , TO BE ADAPTED DURING ASSEMBLY, Replaced By: A9703250184
29
SHIM BETWEEN THE SPRING LEAVES
29
SHIM BETWEEN THE SPRING LEAVES, TO BE ADAPTED DURING ASSEMBLY
29
SHIM , Replaced By: A9703250184
35
SPRING BOLT
38
HEXAGON NUT. NUT SPRING BOLT
38
NUT , Replaced By: N910113012005
44
SPRING CLAMP
50
SCREW RUBBER BUFFER TO SPRING LEAF
53
NUT OIL TANK TO BRACKET
53
NUT , Replaced By: N913002006009
59
RIVET SPRING CLAMP TO SPRING LEAF
74
THRUST WASHER REAR SPRING TO REAR SPRING FRONT BRACKET
77
SHACKLE (SPRING SHACKLE)
80
BUSHING REAR SPRING TO REAR SPRING REAR BRACKET
83
SCREW VIBRATION ABSORBER TO CONSOLE
83
SCREW , Replaced By: N000960018072
86
NUT INTERMEDIATE LEVER TO STEERING SUPPORT
86
NUT , Replaced By: N910113018004
95
SHIM BETWEEN THE SPRING LEAVES, TO BE ADAPTED DURING ASSEMBLY
95
SHIM , TO BE ADAPTED DURING ASSEMBLY, Replaced By: A9703210184
104
PLATE REAR SPRING TO REAR AXLE
107
U-BOLT REAR SPRING TO REAR AXLE 370 MM
110
WASHER FRONT SPRINGS TO FRONT AXLE
113
NUT FRONT SPRINGS WITH TORSION BAR TO FRONT AXLE
119
BRACKET , TO BE ADAPTED DURING ASSEMBLY, Replaced By: A6733200243
125
HELPER SPRING RUBBER BUFFER
128
PIN RUBBER BUFFER
131
SCREW BRACKET TO SIDE MEMBER
131
SCREW , Replaced By: N304017010002
134
SHIM BRACKET TO SIDE MEMBER, TO BE ADAPTED DURING ASSEMBLY
140
NUT STRAP TO BRACKET
140
NUT , Replaced By: N910113010000
