Поз.
Артикул
Описание
5
FUEL TANK125 L,K 169123
5
FUEL TANK ,K 169123, Replaced By: A6704700101
5
FUEL TANK , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. K 169122, Replaced By: A6524700101, +001A0005409917, +001A0115426017
8
FILLER CAP , Replaced By: A0004700305
8
FILLER CAP
8
FILLER CAP , Replaced By: A0004700305
8
FILLER CAP , Replaced By: A0004700305
11
SEAL RING
14
CHAIN FILLER CAP
17
FUEL STRAINER FUEL TANK,K 169122
20
SENDER UNIT FUEL GAUGE,5 218304K 169122
23
SENDER UNIT FUEL GAUGE,K 169123
26
PLUG TO SEAL AUXILIARY HEATER CONNECTION 8 MM,K 169123
29
FUEL STRAINER FUEL TANK,K 169123
32
SEAL RING FUEL GAUGE SENDER UNIT TO FUEL TANK
35
CONNECTOR FEED LINE AND RETURN LINE 8X1 MM
35
CONNECTOR FEED LINE AND RETURN LINE 11X1,5 MM
35
CONNECTOR FEED LINE AND RETURN LINE 12,5X1,25 MM
38
GASKET KIT CONNECTION ON FUEL GAUGE SENSOR
41
LOCK FUEL GAUGE SENDER UNIT CONNECTION
44
VALVE BREATHER LINE,K 169122
44
VALVE ,K 169122
47
BOOT CHECK VALVE,K 169122
50
SCREW PLUG FUEL TANK
50
SCREW PLUG , Replaced By: N007604014110
53
SEAL RING AT TANK
56
SUPPORT FUEL TANK
59
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
59
SCREW , Replaced By: N308676012026
59
SCREW CONSOLE TO SIDE MEMBER
59
SCREW CONSOLE TO SIDE MEMBER
62
WASHER FRONT CONSOLE
62
WASHER FRONT CONSOLE
62
WASHER BRACKET TO FRAME
65
STRAP FUEL TANK TO SUPPORT
68
PAD FUEL TANK TO SUPPORT, ORDER BY THE METER
71
PAD FUEL TANK TO SUPPORT, ORDER BY THE METER
74
STOP
77
NUT SUPPORT TO SIDE MEMBER
