Поз.
Артикул
Описание
5
STEERING BRACKET
5
STEERING SUPPORT (STEERING BRACKET)
8
PIN
11
SCREW TRAILER COUPLING TO REAR CROSS MEMBER
14
NUT , Replaced By: N910113016001
14
NUT CONSOLE TO SUPPORT
17
SCREW , Replaced By: N308676016007
17
SCREW BEARING BRACKET TO REAR AXLE M 16X1.5X50
23
SCREW TRAILER COUPLING TO REAR CROSS MEMBER
23
SCREW TRAILER COUPLING TO REAR CROSS MEMBER
29
PITMAN ARM
29
PITMAN ARM , Replaced By: A6754631701
32
NUT PITMAN ARM TO STEERING BOX ASSEMBLY
35
DRAG LINK , Replaced By: A6754602405
35
DRAG LINKLEMFOERDER
35
DRAG LINK , Replaced By: A6754603005
35
DRAG LINKEHRENREICH
35
DRAG LINK , Replaced By: A6754602505
35
DRAG LINKLEMFOERDER
35
DRAG LINK , Replaced By: A6754603105
35
DRAG LINKEHRENREICH
38
BOOT , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0003300885
38
BOOT FIXED PART OF JOINT
41
DRAG LINK END , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0004602648
41
DRAG LINK END ,K 055088
41
DRAG LINK END , Replaced By: A0004602748
41
DRAG LINK END TO BE SCREWED INTO DRAG LINK EHRENREICH
44
BOOT SCREWED PART OF JOINT
47
CLAMP DRAG LINK END TO DRAG LINK LEMFOERDER
47
CLAMP DRAG LINK END TO DRAG LINK EHRENREICH
50
SCREW ,5 903514, Replaced By: N000960012353
50
SCREW TORSION BAR TO SHACKLE,5 903514
53
NUT , Replaced By: N910113012003
53
HEXAGON NUT EXHAUST PIPE TO BRACKET ON SIDE MEMBER
56
NUT DRAG LINK TO STEERING ARM AND PITMAN ARM
59
COTTER PINROCKINGER TYP 260 G140
62
NUT DRAG LINK TO LEVER,4 215305
65
COTTER PINROCKINGER TYP 260 G140
