Поз.
Артикул
Описание
5
FRONT SPRING (PARABOLIC SPRING),NUMBER OF LEAVES: "2"
5
FRONT SPRING (PARABOLIC SPRING),NUMBER OF LEAVES: "2"
8
SHIM BETWEEN THE SPRING LEAVES, TO BE ADAPTED DURING ASSEMBLY
8
SHIM , Replaced By: A9703210184
11
RUBBER BUFFER BETWEEN THE SPRING LEAVES
11
RUBBER BUFFER BETWEEN THE SPRING EYES
11
RUBBER BUFFER BETWEEN THE SPRING EYES
14
SHIM BETWEEN THE SPRING LEAVES, TO BE ADAPTED DURING ASSEMBLY
14
SHIM , Replaced By: A9703250184
17
SCREW , Replaced By: N007984006036
17
SCREW
20
NUT PUMP TO BRACKET
20
NUT , Replaced By: N913004006001
23
SPRING BOLT
23
SPRING BOLT
26
NUT , Replaced By: N910113012005
26
HEXAGON NUT. NUT SPRING BOLT
29
SPRING CLAMP FRONT SPRING TO SPRING SHACKLE & SPRING BRACKETS
38
RUBBER BUFFER FRONT SPRING TO SPRING SHACKLE & SPRING BRACKETS
44
SCREW ENGINE MOUNTING TO CONSOLE M 18X150
71
RUBBER MOUNTING
71
BUSHING , Replaced By: A9703200344
71
BUSHING
74
BUSHING FRONT SPRING TO FRONT SPRING FRONT BRACKET,5 508030
74
BUSHING FRONT SPRING TO FRONT SPRING FRONT BRACKET,5 358487
77
SHACKLE SPRING SHACKLE TO SPRING REAR BRACKET, RIGHT
77
SHACKLE SPRING SHACKLE TO SPRING REAR BRACKET, LEFT
80
SHACKLE FRONT SPRING TO FRONT-SPRING REAR BRACKET,5 358487
80
SHACKLE OUTSIDE,FRONT SPRING TO SPRING REAR BRACKET
80
SHACKLE OUTSIDE,FRONT SPRING TO SPRING REAR BRACKET
83
SHACKLE FRONT SPRING TO FRONT-SPRING REAR BRACKET
83
SHACKLE INSIDE,FRONT SPRING TO SPRING REAR BRACKET
83
SHACKLE INSIDE,FRONT SPRING TO SPRING REAR BRACKET
86
SCREW FRONT SPRING TO FRONT SPRING FRONT BRACKET
86
SCREW FRONT SPRING TO FRONT-SPRING REAR BRACKET
86
SCREW ENGINE TO ENGINE FRONT SUPPORT M16X135,5 548534
89
NUT TRAILER COUPLING TO REAR CROSS MEMBER M 16
89
NUT TORSION BAR TO BEARING BRACKET,5 904661
92
HELPER SPRING , TO BE ADAPTED DURING ASSEMBLY, Replaced By: A6733240408
92
HELPER SPRING FRONT SPRING STOP
95
PLATE FRONT SPRINGS TO FRONT AXLE
98
SHIM FRONT AXLE
98
SHIM FRONT SPRING TO FRONT AXLE,LEFT
98
SHIM FRONT AXLE,RIGHT
98
SHIM FRONT AXLE,LEFT
98
SHIM FRONT SPRINGS TO FRONT AXLE
101
SHIM , TO BE ADAPTED DURING ASSEMBLY, Replaced By: A6733221684
101
SHIM , TO BE ADAPTED DURING ASSEMBLY, Replaced By: A6733221684
101
SHIM , TO BE ADAPTED DURING ASSEMBLY, Replaced By: A6733221684
101
SHIM FRONT SPRINGS TO FRONT AXLE
104
SHIM FRONT SPRING TO FRONT AXLE,LEFT
107
CENTERING BOLT FRONT SPRINGS TO FRONT AXLE 25 MM
107
DOWEL PIN BETWEEN SPRING AND FRONT AXLE
107
DOWEL PIN FRONT AXLE 65 MM
107
DOWEL PIN FRONT SPRINGS TO FRONT AXLE 38 MM
107
DOWEL PIN FRONT SPRINGS TO FRONT AXLE 25 MM, Replaced By: A9303230474
107
DOWEL PIN BETWEEN SPRING AND FRONT AXLE
107
DOWEL PIN FRONT SPRINGS TO FRONT AXLE 31 MM
110
U-BOLT FRONT SPRINGS TO FRONT AXLE 240 MM
110
U-BOLT FRONT SPRING TO FRONT AXLE,FRONT LEFT 220 MM
110
U-BOLT REAR SPRING TO REAR AXLE 340 MM
110
U-BOLT FRONT SPRINGS TO FRONT AXLE 280 MM
110
U-BOLT FRONT SPRING TO FRONT AXLE,FRONT
110
U-BOLT FRONT SPRING TO FRONT AXLE,FRONT 300MM
113
WASHER CONSOLE TO FRAME
116
NUT FRONT SPRINGS TO FRONT AXLE
