Поз.
Артикул
Описание
5
VALVE SELF-LEVELLING DEVICE,MANUAL KNORR, FOR USE WITH MERCEDES-BENZ PLATFORM PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
5
VALVE SELF-LEVELLING DEVICE,MANUAL GRAU, FOR USE WITH MERCEDES-BENZ PLATFORM
8
HANDLE ,5 292411
11
PROTECTIVE CAPTO 000 329 04 25,000 329 08 25,K 186867
11
BOOT ,5 292411
14
VALVETO 000 329 04 25,000 329 08 25,K 186867
17
REPAIR KIT CONTROL VALVE KNORR SV 3111-I/83153,K 186867
17
REPAIR KIT CONTROL VALVE KNORR SV 3111-I/73100,K 186867
17
REPAIR KIT CONTROL VALVE GRAU,K 186867
20
SUPPORT CONTROL VALVE,K 186867
23
SCREW REAR EXHAUST PIPE TO MUFFLER
26
SCREW PIPE CLAMP
26
SCREW , Replaced By: N304017008021
29
WASHER SUPPORT TO SIDE MEMBER,K 186867
32
NUT STRAP TO BRACKET
32
NUT , Replaced By: N910113010000
35
NUT , Replaced By: N913004008001
35
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
38
FITTING DELIVERY LINE TO PUMP
41
GUIDE SIGN AIR SPRING BELLOWS,LEFT AND RIGHT
44
GUIDE SIGN SUPPLY
46
ADHESIVE FOIL GUIDE SIGN
47
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
50
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
53
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
53
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
53
TEST CONNECTION
53
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
56
FITTING PRESSURE REGULATOR,CONNECTION: "40"
59
WASHER
62
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
65
HOLLOW SCREW HEATING CONNECTION
68
SEAL RING LINE CONNECTION
71
VALVE SELF-LEVELLING DEVICE, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
71
VALVE
74
BOOT
77
REPAIR KIT AIR SPRING VALVE
80
BRACKET AIR SPRING VALVE
83
SCREW END PIECE TO EXHAUST PIPE M 10X25
86
SCREW , Replaced By: N304014008001
86
SCREW FRONT AXLE REGULATING SOLENOID VALVE M 8X75
89
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
89
NUT , Replaced By: N913004008001
92
LEVER AIR SPRING VALVE,K 186867
95
SCREW , Replaced By: N304017008023
95
SCREW CABLE HARNESS MOUNTING
98
TOOTHED WASHER LEVER TO AIR SPRING VALVE,K 186867
98
TOOTHED WASHER , Replaced By: N006797008120
101
PULL ROD PNEUMATIC SUSPENSION CONTROL
104
NUT INTERMEDIATE SPEED STOP
104
NUT
107
YOKE BOTTOM
107
YOKE L.H. THREAD, SELF-LEVELLING DEVICE
110
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
110
NUT , Replaced By: N913004008001
113
HOLLOW SCREW HEATING CONNECTION
116
HOLLOW SCREW LINE CONNECTION
119
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
122
SCREW PLUGROCKINGER,TYP 59 U150
122
SCREW PLUG, FILLING. SCREW PLUG 3/2-WAY VALVE,CONNECTION: "10"
122
SCREW PLUG , Replaced By: N000908012009
122
SCREW PLUGROCKINGER TYP 59 G140,59 G150, Replaced By: N007604012105
125
SEAL RING LINE CONNECTION
125
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
