Поз.
Артикул
Описание
59
RESERVOIR AIR RESERVOIRS I AND II,B 883597
59
RESERVOIR INSIDE
62
CONSOLE AIR RESERVOIR
62
CONSOLE , 674067
68
PLATE STRAP
68
PLATE STRAP TO CONSOLE
71
HEXAGON HEAD BOLT BRACKET TO SIDE MEMBER M12X1.5X35
80
NUT BRACKET TO SIDE MEMBER M12X1.5
86
STRAP AIR RESERVOIR TO CONSOLE
92
NUT BRACKET TO RETARDER
104
BASE AIR RESERVOIR TO CONSOLE
116
VALVE. DRAIN VALVE DRAIN
116
VALVE
116
VALVE DRAIN, Replaced By: A0004322107
116
VALVE
116
VALVE DRAIN, Replaced By: A0004322407
125
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
140
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
143
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
146
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
194
AIR DEHYDRATOR"WABCO",5 502947
194
AIR DEHYDRATOR"KNORR",5 502947
194
AIR DEHYDRATOR"BOSCH",5 502947
197
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
200
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
203
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
206
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
209
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
212
HOLLOW SCREW HEATING CONNECTION
215
SEAL RING LINE CONNECTION
218
BRACKET AIR DEHYDRATOR,D 001885
221
HEXAGON HEAD BOLT. SCREW FRONT EXHAUST PIPE TO BRACKET
227
HEXAGON HEAD BOLT RESONATOR TO TRANSMISSION CASE,K 138633
230
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
233
CONNECTOR BRAKE POWER REGULATOR,CONNECTION: "30"
233
CONNECTOR 75 DEGREES
